Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2200 x 900 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 85 kg | |
| Recommended seating capacity | 6 persons | |
| Surface scratch resistance rating | 6 Mohs | |
| Surface heat resistance threshold | 1200 °C | |
| Surface stain resistance level | Grade 5 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | Polished white sintered stone, 12mm thickness, non-porous seamless surface | |
|---|---|---|
| Support columns | Matte black powder-coated carbon steel, 1.5mm wall thickness, solid rectangular profile | |
| Vertical slats | Matte black powder-coated carbon steel, 1.5mm wall thickness, flat bar profile | |
| Frame cross bracing | Matte black powder-coated carbon steel, welded connection for structural rigidity | |
| Base foot pads | Non-slip TPE rubber pads, 5mm thickness, floor-protective design | |
| Tabletop edge finish | Straight polished eased edge, no sharp corners, 1mm radius | |
| Surface coating on steel | Epoxy polyester powder coat, 60μm thickness, anti-corrosion treatment | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Fixed height design | 750mm standard dining height, compatible with 480 mm seat height dining chairs | |
|---|---|---|
| Open base design | Slatted metal framing provides unobstructed leg room for all seating positions | |
| Non-porous tabletop surface | Resists absorption of spills, requires only wiping with damp cloth for cleaning | |
| Scratch and abrasion resistant surface | Withstands daily use from cutlery, crockery and decorative items without permanent marking | |
| Heat resistant tabletop | Allows direct placement of hot serving dishes and cookware without surface damage | |
| Floor protection design | Rubber foot pads prevent scuffing and scratching on hard flooring and low-pile carpet | |
| Stable dual-support base | Two separate support sections distribute weight evenly to eliminate table wobble | |
| Support column width (each solid block) | 150 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Packaged tabletop carton dimensions | 2300 x 1000 x 80 mm | |
|---|---|---|
| Packaged base carton dimensions | 1300 x 700 x 200 mm | |
| Total shipping gross weight | 105 kg | |
| Total shipping volume | 0.37 CBM | |
| Required assembly time | 40 minutes | |
| 20ft container loading capacity | 52 units | |
| 40ft HQ container loading capacity | 124 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm |
Recommended spaces / users / usage modes
| Residential dining room | Suits modern minimalist, light luxury open-plan dining areas for family daily meals and small gatherings | |
|---|---|---|
| Open-plan kitchen dining zone | Fits kitchen island adjacent dining spaces, complements dark and light neutral interior palettes | |
| Small formal meeting space | Suitable for boutique office breakout rooms or client meeting areas for 6-person discussions | |
| Studio apartment dining area | Fits large open studio spaces, provides functional dining surface without visual heaviness | |
| Show home display setting | Ideal for modern residential show home staging to demonstrate contemporary dining configuration |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables, applicable for load and stability testing | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for surface resistance to cold liquids, applicable to tabletop stain testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural stability testing | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances, applicable to metal finish VOC testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural stability testing; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances, applicable to metal finish VOC testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
