Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1600 × 900 × 750 mm | |
|---|---|---|
| Overall assembled dimensions | 1600 x 900 x 750 mm | |
| Tabletop thickness | 27 mm | |
| Support column cross-section | 80 x 80 mm | |
| Floor base dimensions | 1000 x 400 x 10 mm | |
| Under-table knee clearance height | 723 mm | |
| Tabletop edge bevel radius | 2 mm | |
| Column center spacing | 600 mm | |
| Floor base overhang from columns | 200 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Static distributed tabletop load capacity | 200 kg | |
|---|---|---|
| Sintered stone surface temperature resistance | 600 °C | |
| Sintered stone fracture modulus | 40 N/mm² | |
| Product net weight | 100 kg | |
| Seating capacity | 4 people | |
| Powder coating finish abrasion resistance | 2000 cycles | |
| Recommended floor load distribution | 100 kg/m² | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop surface layer | 12mm thick white veined sintered stone | |
|---|---|---|
| Tabletop backing board | 15mm thick high-density fiberboard | |
| Support columns | Square carbon steel tubing, 1.5mm wall thickness | |
| Floor base plate | Flat carbon steel plate, 10mm thick | |
| Metal finish | Matte black powder coating | |
| Tabletop-to-frame connectors | M8 zinc-plated steel bolts | |
| Base floor contact pads | 3mm thick non-slip rubber pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | No height adjustment, fixed 750mm dining height | |
|---|---|---|
| Extension mechanism | No extendable leaves, fixed rectangular top | |
| Assembly type | Knock-down assembly required, columns attach to base and top | |
| Floor protection | Non-slip rubber pads at base corners prevent floor scuffing | |
| Surface maintenance | Non-porous sintered stone surface resists stains and supports wipe-clean care | |
| Mobility | Fixed stationary design, no casters installed | |
| Under-table access | Open unobstructed leg room for 4 seated users | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential small dining room | Fits 4-person dining in compact urban apartments and small homes | |
|---|---|---|
| Cafe and casual restaurant seating | Commercial-grade finish suitable for high-turnover casual dining venues | |
| Open-plan kitchen breakfast nook | Slim profile fits integrated kitchen dining spaces without obstructing walkways | |
| Office break room seating | Durable easy-clean surface suitable for employee break and lunch areas | |
| Apartment rental furnishing | Neutral minimalist design coordinates with most modern interior decor schemes | |
| Small meeting room lounge | Works as a compact meeting table for informal 4-person discussions |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture for domestic dining tables, safety strength and durability requirements | |
|---|---|---|
| EN 13722:2004 | Furniture hardware, strength and durability requirements for connecting bolts |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 44309-2024 | Sintered stone for furniture, applicable to tabletop material performance requirements | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to backing board components | |
| GB/T 4893.8-2013 | Furniture surface abrasion resistance test, applicable to metal coating durability |
This product must meet the following technical requirements: 1. GB/T 44309-2024: Sintered stone for furniture, applicable to tabletop material performance requirements; 2. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to backing board components; 3. GB/T 4893.8-2013: Furniture surface abrasion resistance test, applicable to metal coating durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
