Primary source
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1800 × 900 × 750 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Under-table knee clearance height | 680 mm | |
| Base plinth dimensions | 1200 x 600 x 20 mm | |
| X-pedestal cross section width | 80 mm | |
| Tabletop corner radius | 20 mm | |
| Seating clearance per place setting | 600 mm | |
| Tabletop overhang from plinth edge | 300 mm | |
| Floor to plinth top surface height | 20 mm | |
| Gold accent strip width on X frame | 15 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Table net weight | 115 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 300 kg | |
| Recommended seating capacity | 6 persons | |
| Sintered stone surface heat resistance | 1200 °C | |
| Sintered stone Mohs hardness | 6 | |
| Sintered stone water absorption rate | 0.2% | |
| Sintered stone stain resistance class | 5 | |
| Surface scratch resistance | Resistant to daily cutlery scratches | |
| Manufacturer warranty period | 1 year | |
| Top Static Load Reference | 150 kg uniformly distributed |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop panel | 12mm polished white sintered stone with subtle natural veining | |
|---|---|---|
| X-pedestal structural frame | 1.5mm thick matte light-finish carbon steel | |
| X-frame decorative accent | 1.2mm thick polished gold PVD-coated stainless steel | |
| Base stabilizing plinth | 2.0mm thick matte black powder-coated carbon steel | |
| Tabletop connection hardware | M8 zinc-plated steel mounting bolts with anti-loosening washers | |
| Surface edge treatment | CNC polished rounded edges with 20mm radius, no sharp corners | |
| Protective plinth bottom pads | 5mm thick non-slip EVA rubber floor protection pads | |
| Frame surface finish | Baked matte powder coating with anti-scratch clear topcoat | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Table structure type | Fixed non-extendable dining table with single central X pedestal | |
|---|---|---|
| Legroom configuration | Unobstructed 360° legroom around central pedestal for all seating positions | |
| Surface maintenance | Wipe-clean non-porous surface resistant to common food and beverage stains | |
| Floor protection | Non-slip rubber pads under plinth prevent floor scratching and table sliding | |
| Assembly requirement | Knockdown assembly requiring two adults, tabletop attaches to pre-assembled base frame | |
| Stability design | Wide low-profile rectangular plinth base eliminates tipping risk under normal dining use | |
| Surface use suitability | Heat-resistant top supports placement of hot serving dishes directly from cooking | |
| Seating flexibility | Accommodates up to 6 standard dining chairs without leg obstruction | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Suitable for open-plan modern dining areas seating 6 household members or guests | |
|---|---|---|
| Light luxury interior schemes | Matches minimalist, contemporary, and upscale residential decor styles with mixed metal finishes | |
| Restaurant private dining rooms | Appropriate for small commercial private dining spaces requiring durable elegant table surfaces | |
| Apartment open living spaces | Central pedestal design maximizes legroom for compact open-plan living and dining zones | |
| Show home display sets | Ideal for high-end residential show home dining area staging with matching quilted upholstered chairs | |
| High-rise residential dining areas | Durable non-porous surface suits daily family use with minimal maintenance requirements |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 15185:2006 | Furniture - Test for assessment of surface resistance to abrasion |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability verification | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for any auxiliary structural panels if included | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture | |
| GB/T 19001-2016 | Quality management systems requirement, referenced for production process control |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability verification; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for any auxiliary structural panels if included; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; 4. GB/T 19001-2016: Quality management systems requirement, referenced for production process control; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
