PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1220 × 710 × 760 mm | |
|---|---|---|
| Overall assembled dimensions | 1220 x 710 x 760 mm | |
| Tabletop thickness | 12 mm | |
| Support column diameter | 76 mm | |
| Base plate dimensions | 590 x 500 mm | |
| Table edge bevel | 2 mm | |
| Under-table knee clearance height | 720 mm | |
| Base column center spacing | 380 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 45 kg | |
|---|---|---|
| Distributed static tabletop load | 100 kg | |
| Tabletop heat resistance | 1200 °C | |
| Powder coat finish durability | 1000 abrasion cycles | |
| Floor protection pad thickness | 3 mm | |
| Leveler adjustment range | 10 mm | |
| Warranty period | 2 years | |
| Seating capacity dimension | 4 diners | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop surface | 12mm white marble-vein sintered stone | |
|---|---|---|
| Tabletop substrate | 15mm MDF reinforcement | |
| Support columns | 2mm thick carbon steel tubing | |
| Base plate | 3mm thick folded steel plate | |
| Fastener hardware | Zinc-plated steel bolts and connectors | |
| Foot pads | TPU rubber anti-scratch levelers | |
| Edge finish | Polished beveled sintered stone edge | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | Fixed 760mm dining height, no height adjustment mechanism | |
|---|---|---|
| Floor leveling | 4 adjustable TPU foot pads, 10mm total adjustment range | |
| Assembly structure | Knock-down bolted connection between top, columns and base | |
| Surface performance | Scratch, stain and heat resistant non-porous top | |
| Seating configuration | Perimeter seating for up to 4 diners, central base blocks central leg position | |
| Floor protection | Integrated anti-scratch pads prevent hard base contact with finished floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Commercial cafe dining | Suitable for fast-casual restaurants and coffee shops seating 4 guests | |
|---|---|---|
| Small residential dining nook | Fits compact apartment dining areas for daily household use | |
| Break room use | Appropriate for office pantry and employee break areas | |
| Bistro patio indoor seating | Suitable for enclosed patio and bistro indoor dining areas | |
| Co-working lounge | Works as shared work and dining surface in co-working lounge zones |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 15372:2008+A1:2016 | Furniture – Strength, durability and safety for non-domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for table stability |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF substrate | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to MDF backing |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF substrate; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to MDF backing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
