Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1630 x 775 x 910 mm | |
|---|---|---|
| seat height | 450 mm | |
| seating surface length | 1520 mm | |
| raised backrest height at highest point | 460 mm | |
| seat width at widest point | 775 mm | |
| seat width at foot end | 520 mm | |
| cushion thickness at seating zone | 80 mm | |
| leg height | 250 mm | |
| steel leg diameter | 12 mm | |
| support crossbar height from floor | 100 mm | |
| button tuft spacing along central axis | 280 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| net product weight | 25 kg | |
|---|---|---|
| static weight capacity | 159 kg | |
| recommended user count | 1 person | |
| foam density (seat core) | 35 kg/m³ | |
| foam density (backrest) | 28 kg/m³ | |
| fabric abrasion resistance (Martindale) | 30000 cycles | |
| frame static load cycle rating | 10000 cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| upholstery fabric | Olive green woven polyester fabric, matte finish | |
|---|---|---|
| seat cushion fill | High-density polyurethane foam wrapped in polyester batting | |
| internal frame | 18 mm thick engineered plywood frame with curved formed edges | |
| seating support system | Sinuous spring suspension secured to frame under foam core | |
| tufting hardware | Fabric-covered matching buttons secured with internal twine ties | |
| leg structure | Matte black powder-coated 12 mm diameter steel rod legs with cross-bracing | |
| floor glides | Injection-molded black nylon floor glides at each leg base | |
| edge stitching | Matching thread sewn with 30 mm stitch pitch along fabric seams | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| frame configuration | Fixed non-reclining integrated curved frame, no adjustable mechanisms | |
|---|---|---|
| seating posture support | Contoured undulating profile supports semi-reclined posture for reading or resting | |
| leg assembly | Tool-secured leg attachment to pre-installed frame mounting plates | |
| floor protection | Nylon glides on all leg ends prevent scuffing on hardwood, tile, or carpet surfaces | |
| tufting function | Button tufting secures fabric and fill to prevent shifting and maintain curved silhouette | |
| cleaning access | Fixed upholstered surface allows spot cleaning with mild upholstery detergent | |
| repositioning capability | Lightweight steel leg design allows two-person repositioning within a room | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| shipping carton dimensions | 1860 x 340 x 360 mm | |
|---|---|---|
| gross shipping weight | 29.5 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| modern living room accent seating | Placed as a statement lounge piece near a window or feature wall for relaxed seating | |
|---|---|---|
| bedroom end-of-bed lounger | Positioned at the foot of a bed for dressing, reading, or extra guest seating | |
| boutique hotel lobby seating | Used in reception areas or lounge zones for stylish guest relaxation | |
| private study reading nook | Placed adjacent to a bookshelf or reading lamp for extended seated relaxation | |
| open-concept lounge space divider | Positioned to define seating zones without blocking sight lines in open floor plans | |
| residential color option availability | Available in multiple woven fabric color options to coordinate with decor palettes |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Domestic furniture: seating, test method for stability, applicable for tip resistance verification | |
|---|---|---|
| EN 12520:2015 | Domestic furniture: seating, strength, durability and safety requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal wood frame components | |
|---|---|---|
| GB 18584-2001 | Indoor decorating materials: limit of harmful substances in wood furniture, applicable for emission testing | |
| GB/T 1952.1-2012 | Performance test methods for upholstered sofas, applicable for static and fatigue load testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal wood frame components; 2. GB 18584-2001: Indoor decorating materials: limit of harmful substances in wood furniture, applicable for emission testing; 3. GB/T 1952.1-2012: Performance test methods for upholstered sofas, applicable for static and fatigue load testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
