Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 4000 x 1340 x 850 mm | |
|---|---|---|
| Seat height | 440 mm | |
| Seat depth | 680 mm | |
| Seat cushion thickness | 200 mm | |
| Back cushion thickness | 150 mm | |
| Armrest height above seat | 180 mm | |
| Armrest width at outer edge | 220 mm | |
| Throw pillow dimensions | 450 x 450 mm | |
| Leg height (base clearance) | 20 mm | |
| Modular segment width (each of 2 pieces) | 2000 mm | |
| Backrest height above seat | 410 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total static load capacity | 800 kg | |
|---|---|---|
| Seat cushion compression resilience | 60% | |
| Net weight range | 160 kg | |
| Fabric abrasion resistance (Martindale) | 30000 cycles | |
| Seat firmness rating | Medium | |
| Recommended user count | 4 people | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat | |
| Upholstery Seam Pitch | 4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal frame | Kiln-dried solid pine wood and 18mm plywood with reinforced corner blocking | |
|---|---|---|
| Seat and back upholstery | 400g/m² textured light beige woven polyester-cotton blend fabric | |
| Outer arm trim | Dark charcoal top-grain leather or high-grade PU leather match wrap | |
| Seat cushion fill | 35kg/m³ high-density polyurethane foam core wrapped with 50mm down and polyester fiber blend | |
| Back cushion fill | Blown polyester fiber and shredded foam mix, 25kg/m³ fill density | |
| Seat suspension | 80mm wide elastic webbing, 4cm spacing, cross-laced under seat frame | |
| Modular connection hardware | 3mm thick powder-coated steel connector brackets with bolt fixation | |
| Seam construction | 10 stitches per 50mm tone-on-tone matching thread stitching | |
| Throw pillow covers | Mixed light woven fabric, dark woven fabric, and long-pile faux fur for accent pillow | |
| Base plinth | Matte black powder-coated MDF or engineered wood trim, 20mm height | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Modular assembly | Two curved segments connect via embedded steel brackets to form a continuous arc; connection allows on-site repositioning without frame damage | |
|---|---|---|
| Lounge seating support | Deep 680mm seat depth supports cross-legged and reclined lounge postures for residential relaxation | |
| Arm wrap function | Wide curved outer arm wraps provide padded arm support and structural edge protection for both end seating positions | |
| Structural stability | Reinforced corner frame joints prevent warping or loosening during regular long-term seating use | |
| Accent pillow adjustability | Included throw pillows are loose and repositionable to adjust lumbar and back support for individual users | |
| Foot configuration | Low-profile plinth base eliminates exposed legs for a sleek, unified silhouette; no height adjustment mechanism present | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Package count | 3 packages | |
|---|---|---|
| Largest carton dimensions | 2050 x 1390 x 890 mm | |
| Total packaged gross weight | 190 kg | |
| Total packaging volume | 2.54 CBM | |
| Packaging materials | EPE foam wrap, hard corrugated corner protectors, 5-layer corrugated carton, moisture-proof plastic inner bag | |
| Assembly time | 60 minutes | |
| 40HQ container loading quantity | 18 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Large open-plan residential living room | 4-meter curved width fits open floor plan layouts in premium apartments and villas, creating a central lounge focal point | |
|---|---|---|
| High-end hotel lobby lounge area | Sleek curved silhouette and durable upholstery suit hospitality public seating areas for guest relaxation | |
| Executive office reception lounge | Formal yet comfortable design provides guest seating for senior office reception and informal meeting spaces | |
| Luxury residential show home display | Contemporary curved design with contrast light/dark finish serves as a statement furnishing for real estate show home staging | |
| Configuration recommendation | Pair with a 1400 mm diameter curved coffee table to align with the sofa arc, maintaining 450 mm clearance between table edge and seat front for easy access |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture - Strength, durability and safety - Requirements for domestic seating, applicable to structural performance verification | |
|---|---|---|
| EN 1021-1:2014 | Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette, applicable to fire safety performance testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame structural strength and dimensional tolerance verification | |
|---|---|---|
| GB 20400-2006 | Limit of harmful substances in leather and fur, applicable to verification of formaldehyde and heavy metal content in dark arm trim material | |
| GB/T 1952.1-2012 | Upholstered sofas, applicable to seat durability, load capacity, and structural stability testing for acceptance | |
| GB 18401-2010 | National general safety technical code for textile products, applicable to fabric upholstery formaldehyde, pH, and colorfastness testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame structural strength and dimensional tolerance verification; 2. GB 20400-2006: Limit of harmful substances in leather and fur, applicable to verification of formaldehyde and heavy metal content in dark arm trim material; 3. GB/T 1952.1-2012: Upholstered sofas, applicable to seat durability, load capacity, and structural stability testing for acceptance; 4. GB 18401-2010: National general safety technical code for textile products, applicable to fabric upholstery formaldehyde, pH, and colorfastness testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
