| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3134 x 1610 x 889 mm | |
|---|---|---|
| Seat height from floor | 480 mm | |
| Main section seat depth | 671 mm | |
| Chaise lounge depth | 1610 mm | |
| Armrest height from seat | 200 mm | |
| Backrest height from seat | 410 mm | |
| Support foot height | 100 mm | |
| Per-seat module width | 780 mm | |
| Seat cushion thickness | 250 mm | |
| Backrest cushion thickness | 230 mm | |
| Armrest diameter | 220 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total static load capacity | 544 kg | |
|---|---|---|
| Recommended seating capacity | 4 people | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Frame moisture content | 12% | |
| Fabric abrasion resistance | 30000 double rubs | |
| Product net weight | 136 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal frame | Kiln-dried solid hardwood | |
|---|---|---|
| Seat suspension | Sinuous spring support system | |
| Cushion fill | High-density polyurethane foam with fiber wrap | |
| Upholstery fabric | Olive green plush velvet (350 gsm) | |
| Tufting hardware | Polished metal tufting buttons | |
| Support feet | Natural finished rounded solid wood feet | |
| Seam construction | Reinforced stitched seams with 8 mm stitch pitch | |
| Module connectors | Metal interlocking clips between modules | |
| Back cushion core | Blended polyester fiber wrap over foam | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Modular configuration | Reconfigurable connected seat/chaise units via metal clip connectors | |
|---|---|---|
| Cushion design | Removable seat and back cushions for easy cleaning | |
| Chaise orientation | Reversible left/right chaise placement to suit room layout | |
| Seat support | Sinuous spring suspension provides even weight distribution and sag resistance | |
| Foot assembly | Screw-in wooden feet requiring no additional tools for installation | |
| Armrest function | Padded rounded bolster armrests support arm resting and side leaning | |
| Tufting function | Grid button tufting secures cushion fill to prevent shifting and maintain shape | |
| Surface cleaning | Spot-cleanable upholstery with damp cloth for regular maintenance | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Primary lounge seating for family rooms and open-plan living spaces | |
|---|---|---|
| Apartment lounge areas | Compact L-layout maximizes seating without occupying excessive floor space | |
| Casual reception spaces | Comfortable guest seating for boutique offices or studio waiting areas | |
| Home media rooms | Deep chaise and plush cushions support extended seated viewing sessions | |
| Recommended pairing | Pair with low-profile round coffee tables 450 mm tall to match sofa seat height | |
| User group | Designed for adult residential users seeking casual, comfortable lounge seating |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture strength, durability, safety for seating | |
|---|---|---|
| EN 1021-1:2019 | Upholstered furniture ignitability resistance (smouldering cigarette) |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to solid wood frame | |
|---|---|---|
| GB 20400-2006 | Leather/furLimit of harmful substances,applies to upholstered furniture safety | |
| GB/T 1952.1-2012 | Technical requirements for upholstered sofas, applicable seating performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to solid wood frame; 2. GB 20400-2006: Leather/furLimit of harmful substances,applies to upholstered furniture safety; 3. GB/T 1952.1-2012: Technical requirements for upholstered sofas, applicable seating performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
