Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3590 x 1918 x 900 mm | |
|---|---|---|
| Seat height from floor | 430 mm | |
| Standard seat depth (non-chaise sections) | 590 mm | |
| Chaise lounge extended depth | 1350 mm | |
| Seat width per modular seating position | 711 mm | |
| Backrest height above seat surface | 470 mm | |
| Integrated armrest height above seat | 180 mm | |
| Armrest width at curved ends | 200 mm | |
| Seat cushion thickness | 250 mm | |
| Back cushion thickness | 200 mm | |
| Low platform base height | 120 mm | |
| Minimum required clearance for placement | 300 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total static weight capacity | 340 kg | |
|---|---|---|
| Per-seat static weight capacity | 113 kg | |
| Net product weight range | 136 kg | |
| Recommended maximum user weight per seat | 110 kg | |
| Seating capacity | 5 adults | |
| Fabric abrasion resistance (Martindale) | 30000 cycles | |
| Fabric lightfastness rating | Grade 5 | |
| Cushion foam density | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Net product weight | 136 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery fabric | Cream short-pile velvet (polyester-based) | |
|---|---|---|
| Internal structural frame | Kiln-dried solid pine and engineered plywood frame | |
| Seat cushion core fill | High-resilience polyurethane foam wrapped with Dacron batting | |
| Back cushion fill | Blend of polyurethane foam and polyester fiber fill | |
| Seat support system | Sinuous steel spring suspension with elastic webbing layer | |
| Low platform base | Engineered wood frame wrapped in matching velvet upholstery, no exposed legs | |
| Modular connection hardware | Powder-coated steel connector brackets between seating modules | |
| Included throw pillows | Matching velvet upholstery with polyester fiber fill | |
| Upholstery seam construction | Concealed stitched seams with 8 stitches per 30mm | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Modular sectional configuration | 4 connected curved modules and 1 right-end chaise module locked together with steel brackets | |
|---|---|---|
| Seating function | Deep plush multi-position lounge seating with 5 adult positions, including extended chaise for reclined leg rest | |
| Integrated armrest support | Curved padded armrests integrated at both left and right ends of the sectional, providing soft arm support at terminal seating positions | |
| Cushion design | Semi-attached seat and back cushions secured to the frame to prevent shifting during use | |
| Cleaning access | Surface cleanable upholstery, with removable cushion covers accessible via hidden zippers | |
| Floor protection | Upholstered fabric base with non-slip felt pads under the platform frame to prevent floor scratching | |
| Placement flexibility | Designed for freestanding placement away from walls due to continuous curved finished profile | |
| Load distribution | Even weight distribution across the full low platform base, no concentrated leg loads to prevent floor indentation on soft flooring | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 6 cartons | |
|---|---|---|
| Largest individual carton dimensions | 1500 x 1000 x 800 mm | |
| Total shipping volume (CBM) | 4.0 CBM | |
| Total gross shipping weight | 165 kg | |
| Required assembly time | 50 minutes | |
| 20ft GP container loading quantity | 10 units | |
| 40ft HQ container loading quantity | 24 units | |
| Minimum required doorway width for delivery | 800 mm | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Open-plan residential living room | Suitable as a central lounge seating piece for large living rooms, providing multi-person seating for family and guest use with a sculptural curved aesthetic | |
|---|---|---|
| Modern luxury apartment lounge | Ideal for high-end residential apartments with minimalist or contemporary interior design, matching neutral cream color palettes and soft textured furnishings | |
| High-end office reception or lounge area | Suitable for upscale office waiting areas, executive lounge zones or creative studio breakout spaces, providing comfortable informal seating for visitors | |
| Hotel penthouse or suite seating | Applicable for luxury hotel suite living areas or VIP lounge zones, offering a premium lounge experience with soft upholstery and generous seating space | |
| Floating room divider placement | Designed for freestanding placement without wall support, acting as a soft spatial divider in large open-plan spaces while maintaining finished upholstery on all sides | |
| Recommended pairing | Pairs with low-profile round stone or metal coffee tables and soft high-pile area rugs, as seen in the reference scene, for a cohesive contemporary lounge arrangement | |
| Recommended furnishing pairing | Pairs with 600 mm high low-profile round stone or metal coffee tables and 20mm pile high-pile area rugs, as seen in the reference scene, for a cohesive contemporary lounge arrangement |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture - Strength, durability and safety - Requirements for domestic seating, applicable for residential use safety and structural performance validation | |
|---|---|---|
| EN 1021-1:2014 | Furniture - Assessment of ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette, applicable for fire safety testing of upholstery and fill materials | |
| EN 1021-2:2014 | Furniture - Assessment of ignitability of upholstered furniture - Part 2: Ignition source match flame equivalent, applicable for residential fire safety compliance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to the internal wood frame structural strength and finishing quality inspection | |
|---|---|---|
| GB 20400-2006 | Limit of harmful substances in leather and fur, applicable if leather upholstery options are selected; for velvet fabric options, test against GB 18401for textile formaldehyde content | |
| GB/T 1952.1-2012 | Test methods for sofas, applicable to seat durability, cushion compression recovery and structural stability performance testing | |
| GB/T 22807-2019 | Furniture mechanical performance test methods for seating, applicable to static load and fatigue testing of seat and backrest structures | |
| GB 18401-2010 | National general safety technical code for textile products, applicable to velvet upholstery formaldehyde and harmful substance content testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to the internal wood frame structural strength and finishing quality inspection; 2. GB 20400-2006: Limit of harmful substances in leather and fur, applicable if leather upholstery options are selected; for velvet fabric options, test against GB 18401for textile formaldehyde content; 3. GB/T 1952.1-2012: Test methods for sofas, applicable to seat durability, cushion compression recovery and structural stability performance testing; 4. GB/T 22807-2019: Furniture mechanical performance test methods for seating, applicable to static load and fatigue testing of seat and backrest structures; 5. GB 18401-2010: National general safety technical code for textile products, applicable to velvet upholstery formaldehyde and harmful substance content testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
