Automatic mm / inch conversion · Core engineering specifications
| Overall L-shaped dimensions | 3410 x 1680 x 740 mm | |
|---|---|---|
| Seat height from floor | 430 mm | |
| Seat depth for straight segment | 900 mm | |
| Seat depth for chaise segment | 1600 mm | |
| Backrest height above seat | 310 mm | |
| Armrest width | 240 mm | |
| Single seating module width | 800 mm | |
| Cushion thickness | 240 mm | |
| Throw pillow dimensions | 500 x 500 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total product weight | 162 kg | |
|---|---|---|
| Overall static load capacity | 360 kg | |
| Seat foam density | 50D high-resilience foam | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 40000 Martindale cycles | |
| Frame static load rating | 600 kg | |
| Spring suspension durability | 100000 compression cycles | |
| Shape retention warranty period | 5 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal frame | Kiln-dried solid pine wood, 30mm thick framing | |
|---|---|---|
| Seat suspension | 3.6mm diameter serpentine steel springs with webbing support | |
| Left segment upholstery | Black-and-white houndstooth woven polyester fabric, 360gsm weight | |
| Right segment upholstery | Caramel brown matte faux leather, 1.2mm thick | |
| Seat cushion fill | 50D high-resilience polyurethane foam wrapped in 200g polyester fiber | |
| Backrest fill | 40D soft polyurethane foam with blown fiber topper | |
| Base structure | Reinforced plywood floor-sitting frame with non-slip felt pads | |
| Stitching detail | High-tenacity polyester thread, 8 stitches per inch seam pitch | |
| Throw pillow fill | Blown polyester fiber fill with removable fabric covers | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Modular connection system | Hidden metal clip connectors between modules for secure alignment | |
|---|---|---|
| Layout flexibility | Supports reconfiguration into straight, L-shaped, or U-shaped layouts via modular clips | |
| Cushion design | Fixed channel-tufted seat and back segments for consistent block shape | |
| Cover maintenance | Removable zippered cushion and pillow covers for spot cleaning | |
| Floor protection | Non-slip felt pads under base to prevent hard floor scratching | |
| Seat function | Deep seat design supports cross-legged or reclined lounge seating | |
| Throw pillow configuration | 4 matching fiber-filled decorative pillows included with the set | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Suitable for open-plan modern living rooms with 4-person seating capacity | |
|---|---|---|
| Apartment open lounge | Fits medium to large apartment spaces with low-profile minimalist aesthetic | |
| Studio reception area | Appropriate for casual creative office or studio reception waiting zones | |
| Villa casual lounge | Suitable for villa family room or media lounge with deep reclined seating | |
| Recommended pairing | Pairs with low oval coffee tables and textured area rugs for cohesive modern interior |
EU Market Access Requirements* EN Standards
| Furniture strength and stability | EN 12520:2015 | |
|---|---|---|
| Upholstered furniture fire resistance | EN 1021:2014 | |
| Furniture hardware performance | EN 15338:2007 |
Standards applicable to China-market projects
| Upholstered furniture safety | GB 20400 | |
|---|---|---|
| Furniture mechanical performance | GB/T 3324 | |
| Textile fabric safety | GB 18401 |
This product must meet the following technical requirements: 1. Upholstered furniture safety: GB 20400; 2. Furniture mechanical performance: GB/T 3324; 3. Textile fabric safety: GB 18401; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
