Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2680 x 1750 x 790 mm | |
|---|---|---|
| Seat height | 381 mm | |
| Seat depth (chaise segment) | 1240 mm | |
| Seat depth (straight main segment) | 648 mm | |
| Left integrated cylindrical armrest diameter | 220 mm | |
| Back cushion height (above seat) | 409 mm | |
| Armrest height (above floor) | 381 mm | |
| Chaise module width | 1940 mm | |
| Main straight segment length | 1930 mm | |
| Seat cushion thickness | 200 mm | |
| Back cushion thickness | 180 mm | |
| Base clearance below sofa | 20 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total static load capacity | 544 kg | |
|---|---|---|
| Recommended seating capacity | 4 people | |
| Foam density (seat core) | 60D | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 30000 Martindale cycles | |
| Net product weight | 165 kg | |
| Seat tilt angle | 15 degrees | |
| Frame warranty period | 10 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery fabric | 380 gsm boucle textured polyester fabric | |
|---|---|---|
| Internal frame | Kiln-dried solid pine wood frame | |
| Seat cushion filling | One-piece shaped 60D high-density polyurethane foam | |
| Back cushion filling | 40D high-density foam wrapped with 100g polyester fiberfill | |
| Seat support layer | 80 mm wide elastic webbing, 50 mm spaced | |
| Base structure | Fully upholstered wrapped pine base frame, no exposed legs | |
| Integrated left armrest | Foam-padded cylindrical form fully wrapped in boucle fabric | |
| Fabric surface treatment | Pilling-resistant and stain-repellent finish | |
| Seam construction | 8 stitches per inch reinforced stitching | |
| Frame hardware | Zinc-plated steel module connecting brackets | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Module configuration | Fixed asymmetric curved L-shape with left chaise | |
|---|---|---|
| Back cushion design | Freely positionable separate rounded back cushions | |
| Cover removability | Fixed non-removable upholstered covers | |
| Seating support | Continuous no-sag webbing support across all seat segments | |
| Armrest function | Integrated padded cylindrical left armrest for lateral support | |
| Recline function | Fixed upright back angle with no recline mechanism | |
| Storage function | No internal storage compartments in seat or base | |
| Floor protection | Non-slip felt pads fitted to base bottom | |
| Customization option | Custom size and multi-color upholstery available | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Suitable for open-plan modern living spaces as primary lounge seating | |
|---|---|---|
| Boutique hospitality space | Ideal for designer hotel lobbies and high-end cafe lounge areas | |
| Residential apartment use | Appropriate for large loft or open-plan apartment seating zones | |
| Design studio reception | Suitable for creative office reception and casual break-out areas | |
| Style compatibility | Pairs with wabi-sabi, minimalist, and French cream-style interior schemes | |
| User group | Designed for households of 5people for daily casual seating |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Strength, durability and safety requirements for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance for smouldering cigarette source |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame construction | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances for wooden furniture, required for indoor residential use | |
| GB/T 1952.1-2012 | Testing standard for upholstered sofas, applicable for durability and safety verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame construction; 2. GB 18584-2001: Limit of harmful substances for wooden furniture, required for indoor residential use; 3. GB/T 1952.1-2012: Testing standard for upholstered sofas, applicable for durability and safety verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
