Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 2800 x 2200 x 1040 mm | |
|---|---|---|
| Seat height from floor | 510 mm | |
| Fixed seat depth (non-chaise seats) | 590 mm | |
| Chaise seat depth (extended lounging area) | 1660 mm | |
| Armrest height from seat surface | 240 mm | |
| Armrest width | 300 mm | |
| Backrest height from seat surface | 530 mm | |
| Support leg height | 150 mm | |
| Seat cushion thickness | 180 mm | |
| Back cushion thickness | 150 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Per-seat static weight capacity | 136 kg | |
|---|---|---|
| Cushion core foam density | 28.8 kg/m³ | |
| Foam rebound rate | 60% | |
| Recline mechanism cycle rating | 10000 cycles | |
| Total sofa static weight capacity | 408 kg | |
| Net weight reference | 145 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat | |
| Upholstery Seam Pitch | 4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery surface | Top-grain leather match or high-abrasion polyester fabric | |
|---|---|---|
| Internal frame | Kiln-dried hardwood with corner-blocked glued and stapled joints | |
| Seat cushion core | 1.8 lb/ft³ high-resilience polyurethane foam with fiber wrap | |
| Seat support system | 8-gauge sinuous steel spring suspension | |
| Support legs | 1.5mm thick matte black powder-coated tapered steel | |
| Recline mechanism hardware | Powder-coated steel power recline linkage with electric actuator | |
| Back cushion fill | Blended polyester fiber and foam layer | |
| Stitching detail | Reinforced polyester thread with 60mm seam pitch | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| Power recline operation | Push-button electric control on left armrest, 130degree backrest recline | |
|---|---|---|
| Footrest deployment | Integrated powered footrest extends 600mm from front seat edge | |
| Seating configuration | Fixed left-hand facing chaise with two additional upright seats | |
| Modular connection | Pre-installed steel bracket connectors between sectional segments | |
| Wall clearance design | Zero-clearance compatible recline operation without moving sofa | |
| Power input | 120V/240V AC electric motor with integrated power cord | |
| Cleaning access | Fixed non-removable cushion covers with wipeable surface | |
| Required wall clearance for recline operation | 110 mm | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Suitable for open-plan living spaces for 3-person daily seating and lounging | |
|---|---|---|
| Home media room | Power recline function supports long-duration viewing comfort | |
| Open-plan lounge area | Neutral light beige finish coordinates with modern and contemporary interior schemes | |
| Small apartment living space | Fixed left chaise layout eliminates unused floor space compared to oversized modulars | |
| Family casual seating | Stain-resistant upholstery option supports regular family use |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
