Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3000 × 1000 × 700 mm | |
|---|---|---|
| Single seat module dimension | 950 x 950 x 700 mm | |
| Seat height from floor | 430 mm | |
| Seat depth per module | 950 mm | |
| Backrest height from seat | 270 mm | |
| Matching ottoman dimensions | 950 x 950 x 380 mm | |
| Armrest width (integrated left arm) | 200 mm | |
| Seat cushion thickness | 220 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total seating capacity | 4 people | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Product net weight | 118 kg | |
| Seat foam density | 45D | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 50000 cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat | |
| Upholstery Seam Pitch | 4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery fabric | 100% polyester beige boucle, 380gsm weight | |
|---|---|---|
| Internal frame | Solid rubberwood frame, 30mm section thickness | |
| Cushion support core | Pocket coil spring system with zigzag spring webbing | |
| Seat cushion fill | 45D high-resilience polyurethane foam, 220mm thickness | |
| Backrest cushion fill | 30D soft polyurethane foam, 180mm thickness | |
| Bottom support feet | Hidden 20mm black plastic floor protectors | |
| Modular connectors | Metal alligator-style clamp connectors | |
| Seam construction | Reinforced stitched seams with 8mm stitch pitch | |
| Included throw pillow | Matching boucle cover with down-alternative fill, 600x600mm size | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular reconfiguration | Clamp-connected square units, supports linear, L-shape or separate ottoman layouts | |
|---|---|---|
| Cushion design | Grid-tufted square segmented cushions, fixed position on frame | |
| Assembly requirement | Tool-free connection of pre-upholstered modules, no full frame assembly needed | |
| Chaise extension | Right-side open chaise segment integrated into the main seating row | |
| Ottoman function | Detachable matching ottoman, usable as footrest or extra seating | |
| Floor protection | Hidden plastic foot pads prevent scratches on hard flooring surfaces | |
| Cleaning access | Removable upholstery covers with hidden zippers for spot cleaning | |
| Reclining support | Deep 950mm seat depth allows relaxed reclined lounge seating | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room | Suitable for open-plan living areas as primary lounge seating for 4 users | |
|---|---|---|
| Small apartment spaces | Reconfigurable modules adapt to compact room layouts without fixed L-shape limits | |
| Lounge and reception areas | Soft textured boucle finish creates welcoming seating for office breakout zones or studio waiting areas | |
| Casual media rooms | Deep seat cushions support extended relaxed seating for movie watching or gaming | |
| Recommended configuration | Pair with low-profile coffee tables 400 mm high to match sofa seat height |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Upholstered furniture safety | EN 1725:1998, applicable for domestic furniture safety and strength requirements for seating | |
|---|---|---|
| Furniture stability | EN 1022:2005, applicable for stability testing of domestic seating furniture |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture safety | GB 28007applicable for structural safety and harmful substance limits for residential sofas | |
|---|---|---|
| Furniture mechanical performance | GB/T 3324applicable for general technical requirements for wooden framed furniture | |
| Textile fabric safety | GB 18401Class B, applicable for direct skin contact upholstery fabric safety limits |
This product must meet the following technical requirements: 1. Upholstered furniture safety: GB 28007applicable for structural safety and harmful substance limits for residential sofas; 2. Furniture mechanical performance: GB/T 3324applicable for general technical requirements for wooden framed furniture; 3. Textile fabric safety: GB 18401Class B, applicable for direct skin contact upholstery fabric safety limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
