Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2870 x 1040 x 1030 mm | |
|---|---|---|
| Seat height from floor | 490 mm | |
| Seat depth per position | 600 mm | |
| Total usable seat width | 2260 mm | |
| Armrest height from floor | 770 mm | |
| Backrest height above seat | 540 mm | |
| Armrest width | 260 mm | |
| Support foot height | 50 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Per-seat weight capacity | 136 kg | |
|---|---|---|
| Total sofa static weight capacity | 408 kg | |
| Upholstery abrasion resistance | 20000 cycles | |
| Cushion foam density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Maximum recline angle from upright | 160° | |
| Frame static load warranty period | 10 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | 1.2mm thick black faux leather, channel-tufted stitching | |
|---|---|---|
| Seat cushion fill | 45kg/m³ high-density polyurethane foam wrapped in polyester fiber | |
| Back cushion fill | 35kg/m³ soft polyurethane foam blended with polyester fiberfill | |
| Internal frame | Kiln-dried solid wood reinforced with 15mm plywood and steel brackets | |
| Recliner mechanism | 2mm thick cold-rolled steel frame with welded joints | |
| Support feet | Injection-molded black plastic with non-slip floor pads | |
| Seam construction | Stitched with bonded polyester thread, 30mm stitch pitch | |
| Armrest padding | 25mm thick foam layer over padded arm frame, soft rolled edge | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| Recline operation | Independent per-seat recline with integrated footrest extension | |
|---|---|---|
| Recline locking | Infinite position lock between upright and 160° full recline | |
| Footrest activation | Synchronized extension with backrest recline for leg support | |
| Wall proximity design | Requires 150mm rear clearance to fully recline without wall contact | |
| Armrest utility | Padded fixed armrests provide stable upper body support when seated | |
| Cushion retention | Segmented seat and back cushions secured to frame to prevent shifting | |
| Floor protection | Non-slip foot pads prevent scuffing and sliding on hard flooring | |
| Minimum wall clearance for recline | 150 mm | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room main seating | Seats three adults comfortably for daily lounge and media use | |
|---|---|---|
| Home theater seating | Recline function supports relaxed viewing positions for extended sessions | |
| Apartment open-plan lounge | Low-profile blocky silhouette fits modern contemporary interior decor schemes | |
| Executive lounge break area | Durable faux leather surface supports regular commercial break space use | |
| Basement recreation room | Stain-resistant black upholstery is suited for casual high-traffic use |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture seating strength, durability and safety requirements | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance for smouldering cigarette source | |
| EN 13356:2009 | Upholstery leather abrasion resistance testing specification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal frame construction | |
|---|---|---|
| GB/T 1952.1-2012 | Sofas standard, applicable to seating safety, durability and dimensional tolerance | |
| GB 18584-2001 | Limit of harmful substances for wooden furniture, applicable to formaldehyde emission control | |
| GB/T 39221-2020 | Upholstered furniture leather performance requirements, applicable to faux leather upholstery |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal frame construction; 2. GB/T 1952.1-2012: Sofas standard, applicable to seating safety, durability and dimensional tolerance; 3. GB 18584-2001: Limit of harmful substances for wooden furniture, applicable to formaldehyde emission control; 4. GB/T 39221-2020: Upholstered furniture leather performance requirements, applicable to faux leather upholstery; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
