Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3410 x 2390 x 890 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat depth (central section) | 530 mm | |
| Chaise seat depth (left) | 1550 mm | |
| Chaise seat depth (right) | 1100 mm | |
| Back cushion size | 500 x 500 mm | |
| Armrest width | 280 mm | |
| Armrest height | 580 mm | |
| Support foot height | 130 mm | |
| Right cantilever side table dimensions | 400 x 300 x 15 mm | |
| Side table height above seat | 20 mm | |
| Seat cushion thickness | 250 mm | |
| Back cushion thickness | 300 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total sofa weight | 260 kg | |
|---|---|---|
| Per-seat static load capacity | 136 kg | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 50000 double rubs | |
| Seam stitch pitch | 8 stitches per inch | |
| Cushion recovery time after unpacking | 72 hours | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal frame | Kiln-dried engineered hardwood with reinforced corner blocking | |
|---|---|---|
| Seat suspension | 3.8 mm diameter sinuous steel springs with polypropylene webbing | |
| Upholstery (seat/back/arms) | Light gray textured woven polyester blend fabric | |
| Lower base panels | Taupe gray smooth matte engineered wood veneer | |
| Seat cushion core | High-resilience polyurethane foam wrapped in 100g dacron fiber | |
| Back cushion filling | Blended down-alternative polyfiber fill | |
| Support feet | Matte black powder-coated steel recessed feet | |
| Right cantilever side table | Engineered wood core with matching taupe gray matte finish | |
| Accent throw pillows | Mixed neutral gray/taupe woven fabric covers with polyfiber fill | |
| Frame joinery | Mortise-and-tenon joints with glued and screwed corner blocks | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Modular configuration | 6 connected seating modules forming U-shape with dual chaise ends | |
|---|---|---|
| Removable cushion covers | Zippered access on all seat and back cushion covers for cleaning | |
| Cantilever side table | Fixed rigid surface attached to right arm for beverage and device placement | |
| Reversible seat cushions | Dual-sided cushion design to extend wear life | |
| Floor protection | Non-marking plastic glides fitted to all support feet | |
| Floating visual design | Recessed feet positioned inward from base edge to create elevated appearance | |
| Modular reconfiguration | Modules separate to allow alternate layout arrangements | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 4 | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Large open-concept residential living rooms | Provides multi-directional seating for 6+ people for family and guest use | |
|---|---|---|
| Modern minimalist and contemporary interior schemes | Neutral light gray and taupe palette complements neutral decor styles | |
| Open-plan lounge and home theater spaces | Dual chaise ends support extended lounging for media viewing | |
| High-end residential and boutique hotel lounge areas | Low-profile floating design delivers premium aesthetic for upscale spaces | |
| Spacious loft and penthouse seating zones | Oversized U-layout fills large floor areas without visual heaviness | |
| Casual entertaining spaces | Integrated side table provides convenient surface placement for gatherings |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture seating strength, durability and safety performance requirements | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance to smoldering cigarette ignition source |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame and base construction | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission control | |
| GB/T 1952.1-2012 | General technical requirements for sofas, applicable to seating durability and safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame and base construction; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission control; 3. GB/T 1952.1-2012: General technical requirements for sofas, applicable to seating durability and safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
