Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1000 × 800 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat depth per module | 660 mm | |
| Seat width per module | 660 mm | |
| Backrest height above seat | 350 mm | |
| Armrest width | 240 mm | |
| Armrest height above floor | 450 mm | |
| Under-sofa clearance | 5 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static load capacity | 450 kg | |
|---|---|---|
| Net product weight | 110 kg | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Seam stitch pitch | 8 stitches per inch | |
| Fabric abrasion resistance | 30000 Martindale cycles | |
| Compressed packaging recovery time | 72 hours | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery fabric | 400gsm beige corduroy polyester | |
|---|---|---|
| Internal frame | 30mm thick kiln-dried solid pine + plywood | |
| Seat cushion fill | 45kg/m³ high-density foam wrapped in 20mm down layer | |
| Back cushion fill | 35kg/m³ high-resilience foam with tufted button anchors | |
| Base structure | Fabric-wrapped engineered wood block frame | |
| Module connectors | Heavy-duty steel snap clips | |
| Throw pillows | Matching corduroy cover with 30kg/m³ polyfill | |
| Fabric backing | Non-woven polypropylene dust cover | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular configuration | Three seat modules connect via steel clips to form straight layout | |
|---|---|---|
| Seating orientation | Fixed upright angled backrest with no recline mechanism | |
| Cover maintenance | Spot clean with damp cloth, non-removable cushion covers | |
| Floor protection | Hidden non-slip felt pads under base perimeter | |
| Throw pillow arrangement | Two included tufted pillows support lumbar or arm use | |
| Installation requirement | Tool-free module alignment and placement upon delivery | |
| Weight distribution | Even floor load across full base footprint | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Living room primary seating | Fits 2400mm wall space for apartment or small family home lounge areas | |
|---|---|---|
| Casual lounge use | Deep seat depth supports relaxed reclined postures for media viewing or socializing | |
| Cream-style interior coordination | Neutral beige finish matches Japandi, minimalist, or warm neutral decor schemes | |
| Small open-plan spaces | Low floor-skirting profile maintains sight lines in compact open concept living areas | |
| Residential reception spaces | Suitable for entry lounge or guest waiting areas in home offices | |
| Area rug placement | Designed to sit fully on large area rugs without sharp leg points damaging pile |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture strength and durability | EN 12520:2015 | |
|---|---|---|
| Formaldehyde emission | EN 13986:2004 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Seating static load test | ANSI/BIFMA X2020 | |
|---|---|---|
| Cushion fatigue test | ANSI/BIFMA X2020 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture safety | GB 17927 | |
|---|---|---|
| Wood frame moisture content | GB/T 3324 | |
| Foam performance | GB/T 10802 |
This product must meet the following technical requirements: 1. Upholstered furniture safety: GB 17927; 2. Wood frame moisture content: GB/T 3324; 3. Foam performance: GB/T 10802; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
