Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3450 x 2840 x 900 mm | |
|---|---|---|
| Seat height from floor | 400 mm | |
| Seat depth | 600 mm | |
| Backrest height above seat | 500 mm | |
| Integrated end armrest width | 220 mm | |
| Seat cushion thickness | 250 mm | |
| Backrest cushion thickness | 180 mm | |
| Plinth base height | 120 mm | |
| Armrest height above seat | 200 mm | |
| Corner inner radius | 800 mm | |
| Single seat module width | 1150 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total product net weight | 140 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Seat foam density | 45D | |
| Seat foam rebound rate | 60% | |
| Upholstery abrasion resistance | 45000 Martindale cycles | |
| Back foam density | 30D | |
| Seam stitch pitch | 30 mm | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery fabric | 380gsm textured woven olive-green polyester blend | |
|---|---|---|
| Internal frame | Kiln-dried solid hardwood with reinforced corner blocking | |
| Seat support system | 80mm diameter pocket coil springs over elastic webbing | |
| Seat cushion fill | 45D high-resilience polyurethane foam wrapped in 20mm dacron batting | |
| Back cushion fill | 30D polyurethane foam blended with polyester fiber fill | |
| Tufting hardware | Reinforced fabric buttons with polyester tufting twine | |
| Plinth base | Fully upholstered hardwood frame with concealed non-marking floor glides | |
| Throw pillow covers | Mixed textured woven fabric in teal and warm gold tones | |
| Seat joinery | Powder-coated steel alligator clip connectors | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Modular segment connection | Steel clip connectors lock seating segments into fixed L-curve | |
|---|---|---|
| Conversational seating layout | Inward-facing curved orientation seats 3 adults | |
| Floor protection | Concealed non-marking glides under plinth base | |
| Integrated armrest support | Rounded padded bolsters at both open ends provide arm support | |
| Cushion retention | Tufting anchors cushion fill to prevent shifting over time | |
| Care and maintenance | Spot-cleanable fabric surface, weekly vacuuming recommended | |
| Fixed position layout | Curved form designed for open-plan living room placement | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Open-plan lounge spaces as primary conversational seating for families | |
|---|---|---|
| Luxury apartment lounge | Compact-to-medium footprint fits modern apartment layouts without sharp edges | |
| Boutique hotel lobby | Curved layout supports casual guest conversation in public seating areas | |
| Design studio reception | Organic silhouette creates a memorable waiting area for creative workplaces | |
| Open-plan lounge zones | Positioned away from walls to highlight curved form for multi-directional seating |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture strength, durability and safety for residential seating, recommended for quality validation | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability test for smouldering cigarette, recommended for fire safety |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal frame construction | |
|---|---|---|
| GB 18401-2010 | National textile product safety class B, applicable to upholstery fabric in direct skin contact | |
| GB/T 1952.1-2012 | Mechanical test standard for upholstered sofas, applicable for load and durability validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal frame construction; 2. GB 18401-2010: National textile product safety class B, applicable to upholstery fabric in direct skin contact; 3. GB/T 1952.1-2012: Mechanical test standard for upholstered sofas, applicable for load and durability validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
