Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2800 × 1000 × 720 mm | |
|---|---|---|
| Seat height from floor | 430 mm | |
| Seat depth | 800 mm | |
| Seat width per module | 1340 mm | |
| Armrest height above seat | 220 mm | |
| Backrest height above seat | 320 mm | |
| Armrest width | 260 mm | |
| Throw pillow size (matching cream) | 500 x 500 mm | |
| Floor clearance under sofa | 0 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static load capacity | 450 kg | |
|---|---|---|
| Seat cushion foam density | 55 kg/m³ | |
| Back cushion fill density | 25 kg/m³ | |
| Fabric abrasion resistance | 12000 cycles | |
| Seat foam rebound rate | 60% | |
| Modular connector cycle life | 100000 cycles | |
| Stain resistance wipe time | 30 seconds | |
| Net weight | 72 kg | |
| Standard color options available | 6 | |
| Stain resistance wipe window | 30 seconds |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery fabric | Cream textured bouclé-style woven polyester blend | |
|---|---|---|
| Internal frame | Kiln-dried solid hardwood + plywood composite | |
| Seat support system | 3.8mm diameter sinuous steel springs with cross webbing | |
| Seat cushion core | 55kg/m³ high-resilience cold-cure PU foam wrapped in dacron | |
| Back cushion fill | 25kg/m³ soft PU foam blended with hollow polyester fiber | |
| Throw pillow covers | Textured fabric matching body, with piping trim | |
| Modular connecting hardware | Zinc-plated steel snap connectors | |
| Bottom base panel | Polyester non-woven dust cover | |
| Seam stitching specification | 8 stitches per inch | |
| Edge padding | 20mm thick soft polyurethane foam wrapping on all arm and seat edges | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular configuration | Two equal straight seat modules connected via steel snap locks | |
|---|---|---|
| Backrest tilt | 15° fixed ergonomic recline for lumbar support | |
| Cushion removability | Seat and back cushions are removable for fabric cleaning | |
| Floor placement | Direct floor contact with no adjustable legs, zero floor clearance | |
| Edge protection | All upholstered edges have 10mm radius rounded soft padding | |
| Pillow adjustability | Three included throw pillows are positionable for lumbar or arm support | |
| Fabric maintenance | Surface stains can be blotted clean with mild detergent within 30 seconds | |
| Backrest support | 15° fixed ergonomic recline with integrated horizontal channel lumbar support | |
| Modular expansion | Compatible with matching corner, chaise and armless modules to extend configuration | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Largest carton dimensions | 2900 x 1050 x 650 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room | Suitable for modern minimalist, cream-style, or wabi-sabi home interiors as primary seating | |
|---|---|---|
| Open-plan lounge space | Ideal for large apartment or open-concept spaces requiring wide casual seating | |
| Designer showroom display | Suitable for furniture showrooms or interior design studio sample displays | |
| Casual reception area | Appropriate for boutique office lounge or creative studio reception seating | |
| Small home media room | Low-profile design does not block sightlines for screen viewing in compact media spaces | |
| Recommended pairing | Matches with low-profile round coffee tables, soft area rugs, and neutral-toned side cabinets | |
| Boutique reception area | Appropriate for creative studio or boutique office lounge reception seating | |
| Compact home media room | Low-profile back design does not block screen sightlines in compact media viewing spaces |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable for domestic seating strength, durability and safety requirements | |
|---|---|---|
| EN 1021-1:2014 | Applicable for upholstered furniture cigarette ignition resistance testing |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB 18401-2010 | Applicable for textile fabric formaldehyde and harmful substance limits | |
|---|---|---|
| GB/T 3920-2008 | Applicable for upholstery fabric color fastness to rubbing testing | |
| GB/T 3324-2017 | Applicable for wooden furniture frame general technical requirement compliance |
This product must meet the following technical requirements: 1. GB 18401-2010: Applicable for textile fabric formaldehyde and harmful substance limits; 2. GB/T 3920-2008: Applicable for upholstery fabric color fastness to rubbing testing; 3. GB/T 3324-2017: Applicable for wooden furniture frame general technical requirement compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
