Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3040 x 1540 x 850 mm | |
|---|---|---|
| Seat height (top of cushion to floor) | 510 mm | |
| Standard seat depth (left and middle positions) | 650 mm | |
| Chaise seat depth (right extended position) | 1540 mm | |
| Individual seat width (per seating position) | 760 mm | |
| Left square arm width | 200 mm | |
| Backrest height (top of cushion to seat surface) | 340 mm | |
| Support foot height | 50 mm | |
| Included square throw pillow size | 550 x 550 mm | |
| Cushion border thickness | 180 mm | |
| Total seating width | 2840 mm | |
| Seat-to-top-backrest angle | 115 degrees | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Per-seat static weight capacity | 136 kg | |
|---|---|---|
| Total combined static weight capacity | 590 kg | |
| Seat foam density | 35 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Back cushion fill density | 24 kg/m³ | |
| Fabric Martindale abrasion resistance | 30000 cycles | |
| Upholstery fabric weight | 380 gsm | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Frame moisture content | 12% | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Inner load-bearing frame | Kiln-dried solid eucalyptus and 15mm plywood | |
|---|---|---|
| Seat support system | 80mm pocket coil springs + polypropylene webbing | |
| Seat cushion core | High-resilience polyurethane foam wrapped in 30mm down blend | |
| Back cushion fill | Loose hollow conjugated polyester fiber blend | |
| Upholstery fabric | Light gray textured nubby 100% polyester boucle-style weave | |
| Support feet | Black matte ABS polymer composite block feet | |
| Inter-unit connectors | Powder-coated steel hook-and-clip fasteners | |
| Throw pillow covers | Polyester fabric with concealed zipper closures | |
| Cushion covers | Removable zippered fabric covers with piped edge detailing | |
| Armrest fill | High-density foam core wrapped in fiber padding | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration | Steel clip connectors allow section repositioning or rearrangement | |
|---|---|---|
| Cushion cover removal | Concealed zippers enable dry-clean removal of all cushion covers | |
| Chaise lounge position | Right-side extended seat supports full reclined leg rest for one user | |
| Fixed back angle | 115-degree fixed reclined back angle supports relaxed lounge seating | |
| Non-marking feet | Smooth flat block feet prevent floor scuffing on hard surfaces | |
| Throw pillow adjustability | Loose throw pillows can be repositioned for neck or back support | |
| Modular assembly | Three separate units connect to form stable L-shaped configuration | |
| Load distribution | Evenly spaced feet distribute weight across floor to prevent frame sag | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living rooms | Provides multi-person casual lounge seating for family and guest use | |
|---|---|---|
| Small apartment open-plan spaces | Compact L-shape fits corner placement to maximize floor space | |
| Loft-style or minimalist interiors | Low-profile blocky silhouette complements modern neutral decor | |
| Casual lounge areas | Supports relaxed seating for movie watching or casual social gathering | |
| Primary bedroom retreats | Plush chaise offers additional reclined seating away from main living areas | |
| Light-use office reception zones | Soft textured finish creates welcoming informal guest seating space |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Domestic furniture seating stability test for L-shaped configurations | |
|---|---|---|
| EN 12520:2015 | Domestic seating strength, durability and safety performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture frame strength and stability | |
|---|---|---|
| GB 18401-2010 | Textile upholstery formaldehyde content limit for direct skin contact | |
| GB/T 1952.1-2012 | Residential sofa durability, static load and impact test requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture frame strength and stability; 2. GB 18401-2010: Textile upholstery formaldehyde content limit for direct skin contact; 3. GB/T 1952.1-2012: Residential sofa durability, static load and impact test requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
