PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	3040 × 1540 × 850 mm
Seat height (top of cushion to floor)	510 mm
Standard seat depth (left and middle positions)	650 mm
Chaise seat depth (right extended position)	1540 mm
Individual seat width (per seating position)	760 mm
Left square arm width	200 mm
Backrest height (top of cushion to seat surface)	340 mm
Support foot height	50 mm
Included square throw pillow size	550 x 550 mm
Cushion border thickness	180 mm
Total seating width	2840 mm
Seat-to-top-backrest angle	115 degrees
Seat Cushion Thickness	180 mm
Back Cushion Thickness	160 mm
Leg Height / Floor Clearance	160 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Per-seat static weight capacity	136 kg
Total combined static weight capacity	590 kg
Seat foam density	35 kg/m³
Seat foam rebound rate	60%
Back cushion fill density	24 kg/m³
Fabric Martindale abrasion resistance	30000 cycles
Upholstery fabric weight	380 gsm
Seam stitch pitch	8 stitches per 30mm
Frame moisture content	12%
Seat Foam Density / Rebound	40 kg/m³ / 60%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Inner load-bearing frame	Kiln-dried solid eucalyptus and 15mm plywood
Seat support system	80mm pocket coil springs + polypropylene webbing
Seat cushion core	High-resilience polyurethane foam wrapped in 30mm down blend
Back cushion fill	Loose hollow conjugated polyester fiber blend
Upholstery fabric	Light gray textured nubby 100% polyester boucle-style weave
Support feet	Black matte ABS polymer composite block feet
Inter-unit connectors	Powder-coated steel hook-and-clip fasteners
Throw pillow covers	Polyester fabric with concealed zipper closures
Cushion covers	Removable zippered fabric covers with piped edge detailing
Armrest fill	High-density foam core wrapped in fiber padding
Timber Frame Section / Moisture	Primary section ≥30 × 50 mm; recommended moisture 12%
Spring / Webbing Specification	Sinuous spring wire 4 mm; elastic webbing 70 mm wide

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Modular reconfiguration	Steel clip connectors allow section repositioning or rearrangement
Cushion cover removal	Concealed zippers enable dry-clean removal of all cushion covers
Chaise lounge position	Right-side extended seat supports full reclined leg rest for one user
Fixed back angle	115-degree fixed reclined back angle supports relaxed lounge seating
Non-marking feet	Smooth flat block feet prevent floor scuffing on hard surfaces
Throw pillow adjustability	Loose throw pillows can be repositioned for neck or back support
Modular assembly	Three separate units connect to form stable L-shaped configuration
Load distribution	Evenly spaced feet distribute weight across floor to prevent frame sag
Cushion Service Configuration	Recommended 2removable/replaceable cushion methods

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Module Carton Dimensions	2200× 1050× 850 mm
Reference Packaging Volume	1.8 m³/item
Reference Packaged Gross Weight	110 kg/item

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Residential living rooms	Provides multi-person casual lounge seating for family and guest use
Small apartment open-plan spaces	Compact L-shape fits corner placement to maximize floor space
Loft-style or minimalist interiors	Low-profile blocky silhouette complements modern neutral decor
Casual lounge areas	Supports relaxed seating for movie watching or casual social gathering
Primary bedroom retreats	Plush chaise offers additional reclined seating away from main living areas
Light-use office reception zones	Soft textured finish creates welcoming informal guest seating space

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1022:2018	Domestic furniture seating stability test for L-shaped configurations
EN 12520:2015	Domestic seating strength, durability and safety performance requirements

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture frame strength and stability
GB 18401-2010	Textile upholstery formaldehyde content limit for direct skin contact
GB/T 1952.1-2012	Residential sofa durability, static load and impact test requirements

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture frame strength and stability;
2. GB 18401-2010: Textile upholstery formaldehyde content limit for direct skin contact;
3. GB/T 1952.1-2012: Residential sofa durability, static load and impact test requirements;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · LSF-MOD-RC-3040

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · LSF-MOD-RC-3040

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · LSF-MOD-RC-3040Open Export Tool

Quick Actions

Post an RFQ

Product Description

This unbranded Light Gray Textured Fabric Right-Chaise L-Shaped Modular Sectional Sofa, model LSF-MOD-RC-3040, features a low-profile, blocky square silhouette defined by a 200mm wide square left arm and clean, structured lines suited to contemporary interiors. Its right-aligned chaise extension forms a compact L-shaped layout made of three connectable units, creating distinct seating zones with uniform individual seat widths and a dedicated extended recline position. The sofa’s inner load-bearing frame is constructed from kiln-dried solid eucalyptus and 15mm plywood, with a seat support system combining 80mm pocket coil springs and polypropylene webbing. Seat cushions feature high-resilience polyurethane foam wrapped in 30mm down blend, paired with back cushions filled with a loose hollow conjugated polyester fiber blend, all supported by black matte ABS polymer composite block feet. Upholstered in light gray textured nubby 100% polyester boucle-style weave, all cushion covers include concealed zippers with piped edge detailing for easy removal, matching the zippered construction of included throw pillow covers. Powder-coated steel hook-and-clip fasteners secure individual units while allowing full reconfiguration of the sectional layout. The right-side chaise delivers a full reclined leg rest for one user, with a fixed 115-degree back angle tuned for relaxed seating. Removable cushion covers support dry cleaning, smooth non-marking feet prevent scuffs on hard flooring, and loose throw pillows can be adjusted to provide targeted neck or back support. The sofa supports a per-seat static weight capacity of 136kg and total combined capacity of 590kg, with fabric rated for 30000 Martindale abrasion cycles to withstand regular use. This sectional fits a range of settings: it serves as multi-person casual lounge seating for residential living rooms, fits neatly into corners to maximize usable floor space in small apartment open-plan layouts, complements neutral minimalist and loft-style decor, supports relaxed seating for movie watching or casual gatherings, adds plush reclined seating to primary bedroom retreats, and creates a welcoming informal seating option for light-use office reception zones. For procurement, note each set ships in two cartons with a total packaged gross weight of 110kg, requires 40 minutes of assembly time, and connects via the included steel clip fasteners to form a stable L-shaped configuration. When planning placement, confirm the overall footprint aligns with intended corner or open layout positions, and account for the right-side chaise orientation to ensure fit within existing space plans.

Light Gray Textured Fabric Right-Chaise L-Shaped Modular Sectional Sofa Specifications
