Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1020 x 820 mm | |
|---|---|---|
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Product net weight (reference) | 95 kg | |
|---|---|---|
| Total static load capacity | 450 kg | |
| Seat foam density | 40 kg/m³ | |
| Backrest foam density | 30 kg/m³ | |
| Seat foam indentation load deflection | 180 N | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Recommended number of users | 3 | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery fabric | Wide-wale corduroy, 450 gsm | |
|---|---|---|
| Seat padding core | High-resilience polyurethane foam, 120mm thickness | |
| Backrest padding core | High-resilience polyurethane foam, 100mm thickness | |
| Internal support frame | Kiln-dried solid pine wood, 30mm frame thickness | |
| Spring support system | Sinuous steel springs, 3.8mm wire diameter | |
| Bottom dust cover | Black non-woven polypropylene fabric | |
| Armrest internal structure | Plywood webbing reinforcement over wood frame | |
| Tufting attachment | Polyester stitching thread, 8mm seam pitch | |
| Base contact feet | Small integrated plastic glides, 20mm height | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed integrated 3-seat layout with continuous curved surface | |
|---|---|---|
| Tufted channel design | Stitched vertical and horizontal channels hold padding in place | |
| Floor protection | Integrated low-profile glides prevent floor scratching | |
| Back support | Contoured multi-height rounded segments provide full lumbar and upper back support | |
| Edge design | Fully rounded arm and seat edges eliminate sharp corners | |
| Installation requirement | Fully assembled delivery, no on-site assembly required | |
| Color option availability | Supports custom fabric color matching for residential projects | |
| Warranty coverage | 2 year structural frame warranty, 1 year upholstery warranty | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Ideal as primary seating for modern, minimalist or contemporary living spaces | |
|---|---|---|
| Lounge and waiting areas | Suitable for high-end office reception, boutique hotel lobby or lounge seating | |
| Showroom and display use | Recommended for furniture showrooms, interior design display suites or creative studio spaces | |
| Small open-plan apartment | Sized appropriately for compact urban living spaces with 3-seat capacity | |
| Recommended placement clearance | Leave minimum 100mm clearance behind sofa for air circulation and cleaning | |
| Recommended pairing | Pairs with rounded velvet ottomans, curved coffee tables and soft area rugs |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
