Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2740 x 2030 x 890 mm | |
|---|---|---|
| Seat height | 460 mm | |
| Seat depth per module | 620 mm | |
| Back cushion height | 480 mm | |
| Left chaise module dimensions | 1140 x 1460 x 890 mm | |
| Support foot height | 50 mm | |
| Individual straight seat module width | 800 mm | |
| Right chaise extension depth | 900 mm | |
| Seat cushion thickness | 250 mm | |
| Back cushion thickness | 180 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Overall static load capacity | 600 kg | |
|---|---|---|
| Seating capacity | 5 people | |
| Cushion foam density | 38 kg/m³ | |
| Cushion foam rebound rate | 60% | |
| Seam stitch pitch | 8 stitches per inch | |
| Upholstery abrasion resistance | 30000 Martindale cycles | |
| Frame joint static load rating | 150 kg per seat | |
| Available colorways | 2 | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery fabric | 350gsm matte polyester-blend fabric | |
|---|---|---|
| Seat cushion core | Multi-layer high-resilience polyurethane foam | |
| Back cushion core | High-resilience foam wrapped in polyester fiber | |
| Internal frame | Kiln-dried engineered wood with corner blocking | |
| Seat suspension | 6-gauge sinuous no-sag spring system | |
| Support feet | Black matte injection-molded plastic block feet | |
| Accent throw pillow fill | 100% loose polyester fiber fill | |
| Tufting stitching | High-tenacity polyester core-spun thread | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration | Modules connect via hidden under-seat clips for left/right chaise adjustment | |
|---|---|---|
| Cushion maintenance | Seat and back cushions are removable for spot cleaning | |
| Multi-position lounge use | Dual chaise segments support upright seated and reclined lounging positions | |
| No integrated armrests | Flush armless edges allow flexible seating access from all sides | |
| Low-profile clearance | 50mm floor clearance prevents dust buildup and allows easy floor cleaning | |
| Static fixed backrest | Integrated tufted backrests provide fixed lumbar support for upright seating | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Largest shipping carton dimensions | 1200 x 850 x 650 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living rooms | Provides multi-person lounge seating for open-concept home spaces | |
|---|---|---|
| Small apartment lofts | Low-profile armless design minimizes visual bulk in compact areas | |
| Contemporary office breakout areas | Casual two-tone design supports informal team collaboration | |
| Studio open-plan spaces | Modular layout adapts to flexible room configurations | |
| Modern rental properties | Durable fabric and neutral two-tone palette suit temporary furnished units |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Applicable for domestic seating stability testing requirements | |
|---|---|---|
| EN 12520:2015 | Applicable for residential sofa strength, durability and safety requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden furniture frames | |
|---|---|---|
| GB 18401-2010 | Applicable for textile upholstery formaldehyde and harmful substance limits | |
| GB/T 1952.1-2012 | Applicable for sofa mechanical performance and durability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden furniture frames; 2. GB 18401-2010: Applicable for textile upholstery formaldehyde and harmful substance limits; 3. GB/T 1952.1-2012: Applicable for sofa mechanical performance and durability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
