Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2250 × 1000 × 970 mm | |
|---|---|---|
| Seat height | 500 mm | |
| Per-seat seat depth | 560 mm | |
| Armrest height from floor | 620 mm | |
| Backrest total height from seat | 470 mm | |
| Leg height | 150 mm | |
| Armrest width (padded) | 180 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total set net weight | 120 kg | |
|---|---|---|
| Per-seat static load capacity | 136 kg | |
| Total set seating capacity | 5 adults | |
| Seat cushion foam density | 45 kg/m³ | |
| Back cushion foam density | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat | |
| Upholstery Seam Pitch | 4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery cover | 1.2 mm thick smooth light beige leather/leatherette, wipe-clean surface | |
|---|---|---|
| Seat cushion core | High-density foam wrapped in 200g polyester fiber batting | |
| Back cushion core | Medium-density foam with fiber wrap for lumbar support | |
| Internal frame | 18 mm thick plywood frame with metal-reinforced seat joints | |
| Seat support base | 8 cm wide serpentine springs with 50 mm elastic webbing | |
| Armrest structure | Padded foam core over solid wood frame, curved ergonomic profile | |
| Support legs | 40 mm diameter dark finished wood/composite legs, floor protective glides | |
| Integrated headrest padding | 200 mm thick shaped foam matching upholstery, fixed non-adjustable | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Fixed 3-seat plus 2-seat conversational group, no reclining mechanism | |
|---|---|---|
| Armrest accessory support | Integrated padded arm tops with matching throw cushions for elbow support | |
| Leg assembly | Knock-down leg installation, no tool requirement for leg attachment | |
| Seat ergonomics | Fixed upright-lounge back angle of 105 degrees for relaxed seating | |
| Floor protection | Hidden plastic glides on leg bases to prevent hard floor scratching | |
| Color and finish | Matte light beige upholstery finish that resists light soiling and is wipe-clean | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room main seating group | Suitable for open-plan living spaces arranged around a central coffee table | |
|---|---|---|
| Small office reception lounge | Appropriate for low-traffic executive waiting areas with modern neutral decor | |
| Apartment lounge seating | Scaled to fit medium-sized apartment living areas without overwhelming space | |
| Showroom display lounge | Suitable for furniture showroom or property sales center seating areas | |
| Matching with low stone coffee tables | Coordinated sizing for pairing with 450 mm tall coffee tables as shown in display |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture strength, durability and safety for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance to smouldering cigarette |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame quality | |
|---|---|---|
| GB 20400-2006 | Leather and fur limit of harmful substances, applicable to leather upholstery |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame quality; 2. GB 20400-2006: Leather and fur limit of harmful substances, applicable to leather upholstery; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
