Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3150 x 2130 x 710 mm | |
|---|---|---|
| Seat height from floor | 470 mm | |
| Seat depth (main sofa section) | 670 mm | |
| Chaise lounge length | 1700 mm | |
| Armrest height from seat | 115 mm | |
| Back cushion height | 460 mm | |
| Throw cushion dimensions | 500 x 500 mm | |
| Support foot height | 30 mm | |
| Armrest width | 250 mm | |
| Seat cushion thickness | 300 mm | |
| Back cushion thickness | 200 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Overall static weight capacity | 1050 kg | |
|---|---|---|
| Per-seat static load capacity | 159 kg | |
| Seat foam density | 35 kg/cu.m | |
| Back foam density | 25 kg/cu.m | |
| Fabric abrasion resistance | 55000 cycles | |
| Fabric lightfastness rating | 5 (8scale) | |
| Foam rebound rate | 60% | |
| Seam stitch pitch | 8 stitches per inch | |
| Net product weight | 147 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal frame | Kiln-dried hardwood and plywood, corner-blocked joinery | |
|---|---|---|
| Upholstery fabric | Charcoal textured 100% polyester fabric, matte finish | |
| Seat cushion fill | High-resiliency polyurethane foam wrapped in polyester fiber | |
| Back cushion fill | Blown polyester fiber wrap over foam core | |
| Throw cushion fill | Polyester fiber fill | |
| Support feet | Black rigid polymer feet with non-marking floor caps | |
| Modular connectors | Reinforced metal connecting brackets between modules | |
| Seat suspension | High-gauge sinuous steel springs with polypropylene webbing | |
| Seam finishing | White contrast polyester topstitching defining all upholstery panels | |
| Armrest construction | Integrated padded wood frame wrapped in foam and fabric | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Modular sectional configuration | Fixed right-facing L-shape with main 3-seat section and right chaise | |
|---|---|---|
| Cushion function | Removable seat and back cushions for cleaning and rotation | |
| Connection mechanism | All-steel interlocking brackets secure modules to prevent shifting | |
| Seating capacity | Accommodates 4 adults comfortably across main seat and chaise | |
| Floor protection | Non-marking polymer foot caps prevent scuffs on hard flooring | |
| Care and maintenance | Spot clean fabric with water-free solvent, vacuum regularly | |
| Assembly requirement | Connect pre-upholstered modules and attach feet upon delivery | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Primary lounge seating for family rooms and open-plan living spaces | |
|---|---|---|
| Small apartment lounge areas | Compact L-shape fits corner layouts to maximize floor space | |
| Home media rooms | Deep plush seats support long-duration seating for movie viewing | |
| Modern minimalist interiors | Low-profile block form and contrast stitching suits contemporary decor | |
| Shared rental properties | Durable fabric construction holds up to regular multi-resident use | |
| Open loft spaces | Low silhouette defines seating zones without blocking sightlines |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture seating: strength, durability and safety requirements | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignition resistance: smouldering cigarette test |
Standards applicable to China-market projects
| GB/T 19520.1-2023 | Upholstered furniture sofas: safety, durability and structural performance requirements | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture for indoor use | |
| GB/T 39223-2020 | Textile fabric abrasion resistance test method for furniture upholstery |
This product must meet the following technical requirements: 1. GB/T 19520.1-2023: Upholstered furniture sofas: safety, durability and structural performance requirements; 2. GB 18584-2001: Limit of harmful substances in wooden furniture for indoor use; 3. GB/T 39223-2020: Textile fabric abrasion resistance test method for furniture upholstery; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
