Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3250 x 1800 x 940 mm | |
|---|---|---|
| Seat height | 510 mm | |
| Sofa section seat depth | 950 mm | |
| Left chaise lounge depth | 1900 mm | |
| Armrest height | 610 mm | |
| Backrest height above seat | 430 mm | |
| Armrest width | 200 mm | |
| Seat cushion thickness | 250 mm | |
| Back cushion thickness | 180 mm | |
| Support foot height | 130 mm | |
| Minimum entry door clearance | 820 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Overall product weight | 118 kg | |
|---|---|---|
| Total static weight capacity | 450 kg | |
| Seating capacity | 4 people | |
| Seat foam density | 40 kg/m³ | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 30000 Martindale cycles | |
| Spring suspension static load rating | 35 kg per individual spring | |
| Seam stitch pitch | 3 stitches per 10mm | |
| Frame warranty | 3 years | |
| Upholstery warranty | 1 year |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal frame | Kiln-dried solid hardwood with mortise-and-tenon joinery | |
|---|---|---|
| Main upholstery fabric | 320gsm matte velvet fabric, two-tone white and caramel brown | |
| Seat core fill | High-density polyurethane foam wrapped in 20mm polyester fiber | |
| Backrest fill | High-resilience polyurethane foam with vertical channel quilting | |
| Seat suspension | 3.8mm gauge sinuous steel springs spaced 100mm apart | |
| Throw pillow fill | 100% shredded polyester fiber fill | |
| Support feet | Black matte polypropylene hidden low-profile feet | |
| Edge detailing | Ruched gathered fabric hem along lower seat perimeter | |
| Armrest construction | Fully padded rounded rolled arms with internal plywood reinforcement | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Modular configuration | 2-piece fixed left-chaise L-shape with locking connector brackets | |
|---|---|---|
| Backrest recline angle | 115 degrees fixed upright lounge angle | |
| Cushion design | Fixed channel-tufted seat and back cushions with non-removable covers | |
| Throw pillow support | Includes 3 matching accent pillows (2 caramel, 1 white) for lumbar support | |
| Floor protection | Glide feet attached to base to prevent hard floor scratching | |
| Module connection | All-metal interlocking brackets secure modules to prevent shifting during use | |
| Chaise lounge function | Full-length left chaise supports full reclined leg rest for one user | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Primary use for family lounge and entertainment spaces in open-plan layouts | |
|---|---|---|
| Apartment open-plan loft | Low-profile scale fits compact urban living areas without visual bulk | |
| Modern office reception | Suitable for casual guest waiting areas in creative studio environments | |
| Matching recommendation | Pairs with low-profile rounded coffee tables 400 mm in height | |
| User profile | Designed for residential consumers seeking minimalist sculptural lounge seating | |
| Placement note | Position against left corner walls to maximize open floor space in rooms |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applies to domestic furniture seating strength, durability and stability requirements | |
|---|---|---|
| EN 1021-1:2014 | Applies to upholstered furniture ignition resistance for smouldering cigarette sources |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applies to wooden frame furniture general technical requirements for domestic sofas | |
|---|---|---|
| GB 20400-2006 | Applies to leather/fabric upholstery limits of harmful substances for residential furniture | |
| GB/T 1952.1-2012 | Applies to upholstered sofas durability and structural performance testing standards |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applies to wooden frame furniture general technical requirements for domestic sofas; 2. GB 20400-2006: Applies to leather/fabric upholstery limits of harmful substances for residential furniture; 3. GB/T 1952.1-2012: Applies to upholstered sofas durability and structural performance testing standards; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
