Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 3200 x 1800 x 700 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Main straight section seat depth | 600 mm | |
| Chaise lounge extended seat length | 1600 mm | |
| Armrest height from floor | 600 mm | |
| Armrest width | 180 mm | |
| Seat cushion thickness | 220 mm | |
| Back cushion thickness | 180 mm | |
| Overall straight sofa section width (excluding chaise) | 2400 mm | |
| Chaise section width | 850 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total static weight capacity | 385 kg | |
|---|---|---|
| Product net weight | 132 kg | |
| Seating capacity | 4 people | |
| High-resilience seat foam density | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Back fill loft retention | 90% | |
| Per-seat static load rating | 110 kg | |
| Recommended warranty period | 1 year limited | |
| Upholstery abrasion resistance | 20000 Martindale rubs | |
| Seam tensile strength | 160 N |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery fabric | 350 gsm smooth matte beige polyester fabric | |
|---|---|---|
| Seat cushion core | 35 kg/m³ high-resilience polyurethane foam with 20mm soft fiber topper | |
| Back cushion construction | Fiber-wrapped foam core with loose removable covers | |
| Internal structural frame | 25mm thick engineered multi-layer wood frame with reinforced corner blocking | |
| Seat support layer | 50mm wide elastic webbing spaced 80mm apart across seat frame | |
| Platform base exterior | Upholstered fabric-wrapped engineered wood block construction | |
| Seam construction | Reinforced stitched seams with 8 stitches per 30mm pitch | |
| Fabric surface finish | Stain-repellent matte finish | |
| Bottom dust cover | Black non-woven polypropylene fabric underbase | |
| Frame moisture content | 12% | |
| Included throw pillow fill | 100% hollow conjugated polyester fiber fill | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% |
Adjustment / rotation / tilt / mobility / storage features
| Modular connection system | Steel connecting clips join straight seat modules and chaise module to prevent shifting during use | |
|---|---|---|
| Cushion configuration | Loose, reversible seat cushions with removable zippered covers for spot cleaning | |
| Back support adjustability | Two tiers of removable back cushions (large upper back, smaller lumbar) for customizable lumbar support | |
| Load distribution design | Continuous platform base distributes weight evenly across floor contact points without concentrated leg loads | |
| Armrest functionality | Padded wrap-around armrests at both ends provide integrated side support and matching visual profile | |
| Assembly requirement | Two-person assembly for module connection and cushion placement; tools provided for hardware tightening | |
| Floor protection | Hidden non-marking felt glides along base bottom edge to prevent hard floor scratching | |
| Block platform base height | 120 mm | |
| Cover removal function | All seat, back and pillow covers have hidden zippers for removal and professional dry cleaning, with seam allowances for reupholstery access | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 3 | |
|---|---|---|
| Largest carton dimensions | 1900 x 920 x 710 mm | |
| Cushion/parts carton dimensions | 900 x 700 x 600 mm | |
| Total shipping gross weight | 145 kg | |
| Total shipping volume | 1.7 CBM | |
| assembly time | 50 minutes | |
| 20ft GP container loading quantity | 18 units | |
| 40ft HQ container loading quantity | 45 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Residential living room primary seating | Suitable for open-plan living areas 30m² or larger, providing ample lounge seating for family and guests | |
|---|---|---|
| Modern minimalist interior schemes | Matches light neutral color palettes, stone accent walls, and low-profile contemporary furniture as seen in the reference scene | |
| Apartment open-plan lounge zones | Low back height preserves sight lines across connected living and dining areas without blocking visual flow | |
| Casual media and lounge spaces | Chaise section supports extended reclining for movie watching or reading, with layered pillows for adjustable support | |
| Home office casual reception areas | Provides soft guest seating for small home office reception zones adjacent to workspaces, with neutral upholstery that coordinates with most office furniture palettes |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture - Strength, durability and safety requirements for domestic seating, applicable to structural load and stability verification | |
|---|---|---|
| EN 1021-1:2014 | Furniture - Assessment of ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette, applicable to fire safety for residential use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to engineered wood frame structural integrity and dimensional stability | |
|---|---|---|
| GB 18401-2010 | National general safety technical code for textile products, applicable to fabric upholstery formaldehyde and harmful substance limits | |
| GB/T 1952.1-2012 | Test methods for sofas, applicable to static load, durability, and seat cushion performance testing | |
| GB 20286-2006 | Fire safety requirements for upholstered furniture in public places, applicable if specified for multi-family residential or common area use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to engineered wood frame structural integrity and dimensional stability; 2. GB 18401-2010: National general safety technical code for textile products, applicable to fabric upholstery formaldehyde and harmful substance limits; 3. GB/T 1952.1-2012: Test methods for sofas, applicable to static load, durability, and seat cushion performance testing; 4. GB 20286-2006: Fire safety requirements for upholstered furniture in public places, applicable if specified for multi-family residential or common area use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
