Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2200 x 900 x 790 mm | |
|---|---|---|
| seat height from floor | 420 mm | |
| usable seat depth | 650 mm | |
| backrest height above seat | 370 mm | |
| seat cushion thickness | 220 mm | |
| backrest cushion thickness | 180 mm | |
| foot height | 40 mm | |
| seating surface length | 2000 mm | |
| rounded end cap radius | 150 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| overall static load capacity | 450 kg | |
|---|---|---|
| net product weight | 65 kg | |
| seating capacity | 3 occupants | |
| seat foam density | 35 kg/m³ | |
| foam rebound rate | 60% | |
| upholstery abrasion resistance | 30000 Martindale cycles | |
| frame joint static load durability | 50000 cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| outer upholstery fabric | Textured woven polyester blend, 380 gsm weight | |
|---|---|---|
| seat cushion core | High-resilience polyurethane foam wrapped with polyester fiber | |
| backrest cushion core | Tufted polyurethane foam with fiber wrap, secured by metal button tufts | |
| internal structural frame | 18 mm thick kiln-dried rubberwood and plywood frame | |
| seat support system | 80 mm wide sinuous steel springs spaced 120 mm apart | |
| decorative front trim | Matching fabric loops secured by metal rings along front seat edge | |
| support feet | 40 mm tall matte black polypropylene block feet | |
| stitching construction | Reinforced bonded nylon thread with 8 mm seam pitch | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| fixed integrated structure | Single assembled upholstered unit with no modular separation | |
|---|---|---|
| seating configuration | Full-width armless seating maximizes usable space for 3 occupants | |
| tufted back support | Button-tufted backrest maintains padded shape with regular use | |
| low-profile support base | Low block feet provide stable, floor-aligned seating posture | |
| fixed backrest angle | 105° reclined fixed back angle for relaxed upright or lounged seating | |
| seat cushion design | Plush overstuffed seat provides deep support for extended sitting | |
| rounded edge design | Curved upholstered end caps eliminate sharp corners for safe placement | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| residential living room | Primary seating for compact to medium-sized open-plan living spaces | |
|---|---|---|
| studio apartment use | Space-efficient 3-seat sofa for small urban dwellings | |
| lounge reception area | Casual guest seating for boutique office or creative studio reception areas | |
| bedroom seating zone | End-of-bed or corner lounge seating in large master bedrooms | |
| complementary modular groupings | Pairs with armless chairs and ottomans to create custom sectional layouts |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture: strength, durability and safety for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Furniture: assessment of upholstered furniture ignitability (smouldering cigarette) |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to internal wood frame | |
|---|---|---|
| GB/T 1952.1-2012 | Upholstered sofas, applies to seating durability and safety performance | |
| GB 18584-2001 | Indoor decorating materials: limit of harmful substances in wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to internal wood frame; 2. GB/T 1952.1-2012: Upholstered sofas, applies to seating durability and safety performance; 3. GB 18584-2001: Indoor decorating materials: limit of harmful substances in wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
