Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2440 x 860 x 790 mm | |
|---|---|---|
| Seat height from floor | 490 mm | |
| Individual seat width | 740 mm | |
| Seat depth (front of seat to back cushion front) | 700 mm | |
| Back cushion height from seat surface | 420 mm | |
| Armrest height from floor | 600 mm | |
| Armrest width (outer frame to inner seat edge) | 150 mm | |
| Under-sofa floor clearance | 200 mm | |
| Seat cushion thickness | 180 mm | |
| Back cushion thickness | 150 mm | |
| Metal frame tube section thickness | 30 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total product net weight | 75 kg | |
|---|---|---|
| Per-seat static load capacity | 136 kg | |
| Seat cushion foam density | 35 kg/cu.m | |
| Back cushion fill density | 20 kg/cu.m | |
| Upholstery fabric abrasion resistance | 55000 cycles | |
| Fabric lightfastness rating | 5 | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Standard residential warranty | 10 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural base frame | Dark matte powder-coated square steel tube, sled configuration with central support legs | |
|---|---|---|
| Seat support inner frame | Kiln-dried solid hardwood and engineered plywood substrate | |
| Seat suspension system | 8-gauge sinuous steel springs with polypropylene webbing cross support | |
| Seat cushion core | 35 kg/cu.m high-resilience cold-cure polyurethane foam with polyester fibre wrap | |
| Back cushion core | Blown polyester fibre wrapped around 20 kg/cu.m polyurethane foam core | |
| Armrest padding | 30 kg/cu.m polyurethane foam wrapped in matching upholstery fabric | |
| Upholstery cover | Taupe matte woven polyester-linen blend fabric with piped edge finishing | |
| Frame foot glides | Injection-moulded nylon floor protection glides at all frame contact points | |
| Cushion attachment | Non-slip fabric underlay to hold loose cushions in place without permanent fixing | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed three-position straight seating with three divided seat and three loose back cushions | |
|---|---|---|
| Cushion reversibility | Seat cushions are fully reversible to extend upholstery wear life | |
| Back cushion adjustability | Loose back cushions can be repositioned for customized lumbar support | |
| Cleaning access | Under-sofa open clearance allows robot vacuums and manual cleaning access | |
| Floor protection | Nylon glides prevent scratching on hard flooring and reduce movement noise | |
| Cover design | Tailored slipcover style fitting over frame and padding for clean modern lines | |
| Structural support | Two additional central support legs prevent long-span frame sag under load | |
| Seat comfort angle | Fixed 8-degree seat rake for relaxed upright lounge seating | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room main seating | Ideal for open-plan modern living spaces as primary three-person lounge seating | |
|---|---|---|
| Studio apartment lounge area | Low-profile open frame suits compact urban living spaces without visual bulk | |
| Office reception waiting area | Contemporary aesthetic fits modern workplace breakout and visitor spaces | |
| Hotel suite lounge area | Durable neutral upholstery suits hospitality guest and public lounge zones | |
| Recommended matching furniture | Pairs with low-profile metal coffee tables and minimalist side tables for coordinated look | |
| Fabric suitability | Neutral taupe upholstery complements light wood, dark wood and monochrome interior palettes | |
| Cleaning suitability | Open under-base clearance supports frequent cleaning in high-traffic domestic or commercial zones |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable standard for domestic furniture seating strength, durability and stability | |
|---|---|---|
| EN 1022:2018 | Applicable standard for seating stability testing for residential upholstered furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for wooden furniture general technical requirements for inner frame components | |
|---|---|---|
| GB 18584-2001 | Applicable standard for formaldehyde emission limits for indoor wooden furniture components | |
| GB/T 1952.1-2012 | Applicable standard for upholstered sofa strength, durability and stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for wooden furniture general technical requirements for inner frame components; 2. GB 18584-2001: Applicable standard for formaldehyde emission limits for indoor wooden furniture components; 3. GB/T 1952.1-2012: Applicable standard for upholstered sofa strength, durability and stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
