Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1900 × 950 × 730 mm | |
|---|---|---|
| Seat height | 370 mm | |
| Seat depth per module | 900 mm | |
| Seat width per module | 900 mm | |
| Armrest height | 600 mm | |
| Backrest height above seat | 360 mm | |
| Leg height | 80 mm | |
| Armrest width | 280 mm | |
| Seat cushion thickness | 200 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 32 kg | |
|---|---|---|
| Overall static load capacity | 300 kg | |
| Seat foam density | 40 kg/m³ | |
| Seat foam rebound rate | 45% | |
| Seat/back durability cycles | 25000 | |
| Seating capacity | 2 adults | |
| Warranty period | 5 years | |
| Upholstery abrasion resistance | 30000 cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Internal frame | Kiln-dried solid hardwood, anti-warping treated | |
|---|---|---|
| Seat support base | Zig-zag sinuous spring support | |
| Seat core fill | Dual-layer high-density polyurethane foam | |
| Backrest fill | Soft high-resilience polyurethane foam | |
| Upholstery cover | Soft cream velvet fabric with channel tufting, zippered removable design | |
| Legs | Dark stained solid rounded wood feet, floor-protecting base | |
| Modular connectors | Hidden metal hook and ring connection system between modules | |
| Seam construction | Reinforced stitched seams with 8mm stitch pitch | |
| Armrest fill | High-resilience foam matching seat and back construction | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular reconfiguration | Modules connect via hidden hardware to form straight or extended configurations | |
|---|---|---|
| Cover removal | Zippered upholstery covers fully removable for cleaning or replacement | |
| Floor protection | Rounded wood legs feature hidden felt pads to prevent floor scratching | |
| Tool-free assembly | Modules connect and legs attach without specialized tools for residential setup | |
| Tufted support | Internal tufting anchors fill to prevent shifting with regular use | |
| Low-profile support | Short legs maintain a grounded, relaxed seating posture | |
| Compressed shipping option | Modules may ship compressed to reduce freight volume | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room | Primary seating for small apartments or open-plan lounge spaces | |
|---|---|---|
| Home office lounge | Casual guest seating for modern home workspaces | |
| Boutique reception area | Stylish soft seating for small studio or retail reception zones | |
| Rental property furnishing | Durable removable covers support easy cleaning between tenants | |
| Compact open-plan loft | Low profile maintains sight lines in open-concept living spaces | |
| Color coordination | Neutral off-white finish pairs with neutral or warm-toned decor palettes |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Domestic furniture seating, stability test requirements for residential sofas | |
|---|---|---|
| EN 12520:2015 | Domestic furniture seating strength durability and safety requirements |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to solid wood frame | |
|---|---|---|
| GB/T 1952.1-2012 | Upholstered furniture sofas, applicable to seating durability and safety | |
| GB 18401-2010 | National general safety technical code for textile products, applicable to upholstery |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to solid wood frame; 2. GB/T 1952.1-2012: Upholstered furniture sofas, applicable to seating durability and safety; 3. GB 18401-2010: National general safety technical code for textile products, applicable to upholstery; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
