Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2950 x 1730 x 790 mm | |
|---|---|---|
| Seat height from floor | 510 mm | |
| Standard sofa seat depth | 670 mm | |
| Right chaise seat depth | 1630 mm | |
| Arm height from floor | 600 mm | |
| Box arm width | 330 mm | |
| Back cushion height above seat | 280 mm | |
| Plinth base height | 65 mm | |
| Seat cushion thickness | 250 mm | |
| Cylindrical arm bolster diameter | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total product weight | 159 kg | |
|---|---|---|
| Total static weight capacity | 454 kg | |
| Per-seat static load capacity | 136 kg | |
| Seating capacity | 4 people | |
| Seat foam density | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Leather abrasion resistance | 50000 cycles | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Structural frame warranty | 5 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and arm upholstery | Full-grain aniline-dyed warm brown leather | |
|---|---|---|
| Throw pillow upholstery | Heavy linen-blend woven fabric | |
| Arm bolster upholstery | Matching brown leather with embossed end detail | |
| Internal frame | Kiln-dried solid hardwood with glued corner blocking | |
| Seat support system | 80mm wide elastic webbing grid under seat cushions | |
| Cushion core fill | High-density polyurethane foam with dacron fiber wrap | |
| Back cushion fill | Blown polyester fiber with down-alternative topping | |
| Base construction | Matte black powder-coated engineered wood plinth | |
| Joiner hardware | Zinc-plated steel alligator clips | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Sectional configuration | Right-facing extended chaise, three straight seat units | |
|---|---|---|
| Cushion installation | Loose removable seat and back cushions | |
| Sectional connection | Interlocking steel joiner clips under seat base | |
| Throw pillow adjustability | Repositionable square and cylindrical bolster pillows | |
| Base stability | Continuous low plinth platform with floor glides | |
| Cleaning access | Removable cushion covers with hidden zipper closures | |
| Weight distribution | Evenly spaced support slats across plinth frame | |
| Orientation compatibility | Fixed right-chaise layout per visual design | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room use | Open-plan loft, modern apartment, or minimalist family lounge | |
|---|---|---|
| Hospitality lounge use | High-end hotel lobbies, executive reception areas, or VIP waiting spaces | |
| Recommended complementary furniture | Low-profile coffee tables, minimal media consoles, and neutral-toned area rugs | |
| User group suitability | Households of 5people, design-focused commercial tenants | |
| Layout recommendation | Position against long open wall with chaise facing outward | |
| Design style fit | Contemporary, minimalist, modern industrial, or warm wabi-sabi interiors |
EU Market Access Requirements* EN Standards
| Domestic furniture safety | EN 12520:2015 | |
|---|---|---|
| Leather upholstery specification | EN 13336:2004 | |
| Upholstered furniture flammability | EN 1021:2014 | |
| Furniture test methods for seating | EN 1728:2012 |
US and Canada office-furniture standards
| Lounge seating durability | ANSI/BIFMA X2020 | |
|---|---|---|
| Seating stability testing | ANSI/BIFMA X2017 |
Standards applicable to China-market projects
| Upholstered furniture safety | GB 20400:2006 | |
|---|---|---|
| Furniture mechanical performance | GB/T 3324 | |
| Flammability of upholstered furniture | GB 20286 | |
| Furniture durability testing | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Upholstered furniture safety: GB 20400:2006; 2. Furniture mechanical performance: GB/T 3324; 3. Flammability of upholstered furniture: GB 20286; 4. Furniture durability testing: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
