Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3000 × 850 × 700 mm | |
|---|---|---|
| Seat height from floor | 430 mm | |
| Seat depth (usable) | 660 mm | |
| Backrest height above seat | 270 mm | |
| Per-seat usable width | 750 mm | |
| Total curved seating length | 2700 mm | |
| Rounded end bolster diameter | 450 mm | |
| Upholstery seam pitch | 30 mm | |
| Base clearance above floor | 0 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Overall static load capacity | 340 kg | |
|---|---|---|
| Seat foam density | 45 kg/m³ | |
| Fabric Martindale abrasion resistance | 50000 cycles | |
| Seat foam rebound rate | 60% | |
| Net product weight | 85 kg | |
| Frame warranty period | 5 years | |
| Cushion and upholstery warranty period | 2 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery fabric | 100% polyester cream textured boucle | |
|---|---|---|
| Internal frame | Kiln-dried solid hardwood with corner blocking | |
| Seat support system | 8-gauge sinuous steel springs with polypropylene webbing | |
| Seat core fill | Multi-density high-resilience foam with Dacron fiber wrap | |
| Backrest fill | Blended high-density foam and polyester fiber | |
| Base construction | Fully upholstered hardwood base with no exposed legs | |
| Throw pillow fill | 100% polyester fiber fill | |
| Adhesive and finishing materials | Low-VOC water-based adhesives and edge treatments | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Stationary continuous 4-person curved lounge seating | |
|---|---|---|
| Assembly requirement | Pre-assembled compression packaged unit, no on-site assembly needed | |
| Design compatibility | Armless kidney shape for open-plan conversational seating layouts | |
| Cleaning compatibility | Removable cushion covers for spot cleaning or dry cleaning | |
| Floor protection | Upholstered non-marking base to prevent hard floor scratching | |
| Modular connectivity | Single integrated unit, no modular connection hardware included | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room | Primary seating for open-plan cream-style living spaces facing a central coffee table | |
|---|---|---|
| Residential lounge/media room | Casual deep-seating for relaxed viewing and social gathering | |
| Boutique hotel lobby lounge | Curved conversational seating for guest reception and waiting areas | |
| High-end apartment common area | Soft welcoming seating for shared resident amenity spaces | |
| Design studio reception | Modern sculptural seating for client waiting and brand display | |
| Luxury villa lounge | Statement seating for large open entertaining zones |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Domestic furniture seating safety | EN 12520:2015 | |
|---|---|---|
| Upholstered furniture flammability | EN 1021:2014 | |
| Furniture formaldehyde emissions | EN 717:2004 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Lounge seating durability | ANSI/BIFMA X2021 | |
|---|---|---|
| Seating stability testing | ANSI/BIFMA X2017(clause 7) |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture safety | GB 20400:2006 | |
|---|---|---|
| Furniture mechanical performance | GB/T 3324 | |
| Fabric safety for furniture | GB 18401 |
This product must meet the following technical requirements: 1. Upholstered furniture safety: GB 20400:2006; 2. Furniture mechanical performance: GB/T 3324; 3. Fabric safety for furniture: GB 18401; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
