Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2170 x 860 x 900 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Seat depth per position | 520 mm | |
| Seat cushion thickness | 220 mm | |
| Back cushion height | 480 mm | |
| Armrest height from floor | 600 mm | |
| Armrest width | 220 mm | |
| Individual seat width | 580 mm | |
| Base ground clearance | 30 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total static load capacity | 340 kg | |
|---|---|---|
| Product net weight | 80 kg | |
| Seat foam density | 32 kg/m³ | |
| Foam rebound rate | 55% | |
| Fabric abrasion resistance | 40000 Martindale cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat | |
| Upholstery Seam Pitch | 4 mm | |
| Recommended Procurement Warranty | Frame 10 years; filling 3 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 380gsm dark green velvet fabric | |
|---|---|---|
| Cushion filling | High-density polyurethane foam core | |
| Internal frame | Dried solid kiln-dried pine wood | |
| Spring support system | 8mm sinuous steel springs | |
| Base frame | Brushed stainless steel continuous plinth | |
| Armrest internal structure | Padded wood frame wrapped in matching velvet | |
| Seam construction | 10mm stitch pitch gathered ruched seams | |
| Upholstery backing | Non-woven fabric dust cover | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | 3 fixed equal-width seating positions | |
|---|---|---|
| Recline function | Fixed upright backrest angle of 105 degrees | |
| Modular connection | Fixed integrated frame, no detachable section connectors | |
| Base support | Continuous low-profile metal plinth, evenly distributes weight across floor | |
| Cushion design | Tight non-removable cushion covers | |
| Armrest support | Padded rolled armrests support forearms in seated and reclined positions | |
| Floor protection | Felt glides attached to base ends to prevent floor scratching | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Primary seating for 3 adults in modern living spaces | |
|---|---|---|
| Reception lounge area | Guest seating for boutique offices, studios or hospitality venues | |
| Open-plan lounge space | Position against feature wall as central low-profile seating anchor | |
| Recommended pairing | Match with low-profile coffee tables 400 mm high | |
| Recommended user group | Residential users and commercial venue operators seeking plush lounge seating |
EU Market Access Requirements* EN Standards
| Upholstered furniture safety | EN 12520:2015 Furniture – Strength, durability and safety for domestic seating |
|---|
Standards applicable to China-market projects
| Structural safety | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Upholstery durability | GB/T 19001Quality management systems | |
| Fabric safety | GB 18401National general safety technical code for textile products |
This product must meet the following technical requirements: 1. Structural safety: GB/T 3324General technical requirements for wooden furniture; 2. Upholstery durability: GB/T 19001Quality management systems; 3. Fabric safety: GB 18401National general safety technical code for textile products; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
