Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2600 x 920 x 890 mm | |
|---|---|---|
| Seat width per position | 620 mm | |
| Seat depth | 620 mm | |
| Seat height from floor | 480 mm | |
| Backrest height above seat | 410 mm | |
| Armrest width | 230 mm | |
| Armrest height from floor | 630 mm | |
| Plinth base height | 120 mm | |
| Seat cushion thickness | 150 mm | |
| Back cushion thickness | 120 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Overall static load capacity | 750 kg | |
|---|---|---|
| Net product weight | 90 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Stitch seam pitch | 30 mm | |
| Leather surface abrasion resistance | 50000 cycles | |
| Frame static load cycle rating | 25000 cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery contact surfaces | 1.4mm thick full-grain/performance faux leather | |
|---|---|---|
| Inner load-bearing frame | Kiln-dried solid pine + 18mm plywood panels | |
| Seat support system | 3.8mm gauge sinuous steel springs + 50mm elastic webbing | |
| Cushion core fill | High-density polyurethane foam with 20mm soft fiber wrap | |
| Armrest internal structure | Plywood frame wrapped in foam and matching upholstery | |
| Lower plinth base | Matte black powder-coated steel + engineered wood substrate | |
| Decorative arm trim | Brushed dark grey metal inlay strip | |
| Frame joint hardware | Metal corner brackets and wood screws | |
| Bottom dust cover | Black non-woven polypropylene fabric | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | 3 fixed segmented seating positions with grid-quilted cushions | |
|---|---|---|
| Recline function | No reclining or adjustable back mechanism | |
| Cushion installation | Fixed attached seat and back cushions | |
| Cleaning access | Surface-wipeable leather upholstery with removable cushion covers | |
| Assembly requirement | Knock-down plinth base attachment only, no full frame assembly | |
| Floor protection | Integrated non-slip felt pads on plinth base bottom | |
| Modular compatibility | Standalone straight unit, no sectional connection hardware | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Primary seating for open-plan or formal living areas | |
|---|---|---|
| Modern office lounge | Guest or employee break area seating | |
| Hotel lobby reception | Premium waiting area seating for upscale properties | |
| Showroom display | Featured display piece for contemporary furniture collections | |
| Apartment open-plan space | Space-appropriate seating for medium to large urban apartments | |
| Recommended pairing | Matches low-profile stone/metal coffee tables and minimalist shelving |
EU Market Access Requirements* EN Standards
| Domestic furniture safety | EN 1725:1998 | |
|---|---|---|
| Upholstered furniture flammability | EN 1021:2014 | |
| Furniture surface durability | EN 14465:2004 |
US and Canada office-furniture standards
| Lounge seating durability | ANSI/BIFMA X2020 |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety | GB 20400 | |
|---|---|---|
| Furniture mechanical performance | GB/T 3324 | |
| Sofa durability testing | GB/T 2012 |
This product must meet the following technical requirements: 1. Upholstered furniture safety: GB 20400; 2. Furniture mechanical performance: GB/T 3324; 3. Sofa durability testing: GB/T 2012; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
