Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1000 × 770 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat depth at center curve | 650 mm | |
| Seat cushion thickness | 220 mm | |
| Backrest height above seat | 350 mm | |
| Armrest height above seat | 180 mm | |
| Curved arc radius at front edge | 1800 mm | |
| Plinth base height | 50 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static load capacity | 450 kg | |
|---|---|---|
| Product net weight | 95 kg | |
| Seat foam density | 45 kg/m³ | |
| Fabric Martindale abrasion resistance | 30000 cycles | |
| Frame moisture content | 12% | |
| Seat cushion rebound rate | 60% | |
| Standard warranty period | 5 years for frame, 1 year for fabric and fill | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| External upholstery | Textured cream boucle-style polyester fabric | |
|---|---|---|
| Internal load-bearing frame | Kiln-dried solid pine wood | |
| Seat core filling | 45D high-resilience polyurethane foam | |
| Backrest filling | Blend of 35D foam and 5A silk wadding | |
| Seat support system | 3.6mm gauge S-shaped sinuous springs + 50mm elastic webbing | |
| Hidden plinth base | Plywood wrapped in matching upholstery fabric | |
| Seam construction | Reinforced stitched seams with 8mm stitch pitch | |
| Included throw pillows | Fabric covers with polyfiber fill | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Fixed 3-person curved seating with wrap-around armrests | |
|---|---|---|
| Cushion design | Integrated fixed seat and back cushions | |
| Base design | Floor-standing plinth base with no visible legs | |
| Functional features | No recline, storage, or integrated power/charging functions | |
| Fabric maintenance | Spot clean only with damp soft cloth | |
| Placement requirement | Freestanding placement with 300mm clearance recommended | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room | Primary lounge seating for modern, wabi-sabi or cream-style interior schemes | |
|---|---|---|
| Boutique commercial lounge | Suitable for high-end retail, beauty salon or hotel reception waiting areas | |
| Open-plan studio space | Functions as central zone divider for large open living or working areas | |
| Upholstery matching recommendation | Pairs with complementary rounded boucle or fabric accent chairs | |
| User group suitability | Designed for adult users seeking relaxed, low-profile lounge seating | |
| Floor surface compatibility | Suitable for placement on low-pile carpet, hardwood or tile flooring |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable for domestic furniture seating strength, durability and stability | |
|---|---|---|
| EN 1021-1:2014 | Applicable for upholstered furniture cigarette ignition resistance |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 10802-2006 | Applicable for flexible polyurethane foam cushion performance testing | |
|---|---|---|
| GB/T 1952.1-2012 | Applicable for upholstered sofa durability and structural safety testing | |
| GB 18584-2001 | Applicable for interior decoration material formaldehyde emission limits |
This product must meet the following technical requirements: 1. GB/T 10802-2006: Applicable for flexible polyurethane foam cushion performance testing; 2. GB/T 1952.1-2012: Applicable for upholstered sofa durability and structural safety testing; 3. GB 18584-2001: Applicable for interior decoration material formaldehyde emission limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
