Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3100 x 1040 x 730 mm | |
|---|---|---|
| Seat height from floor | 400 mm | |
| Seat depth (usable seating) | 680 mm | |
| Seat width per seat position | 700 mm | |
| Backrest height above seat | 330 mm | |
| Armrest height from floor | 600 mm | |
| Armrest width | 200 mm | |
| Integrated side table dimensions | 450 x 350 x 50 mm | |
| Side table height from floor | 600 mm | |
| Plinth base height | 40 mm | |
| Seat cushion thickness | 150 mm | |
| Back cushion thickness | 200 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total static weight capacity | 480 kg | |
|---|---|---|
| Net weight | 200 kg | |
| Seat foam density | 32 kg/m3 | |
| Back foam density | 24 kg/m3 | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Seat support spring gauge | 3.6 mm | |
| Recommended maximum user weight per seat | 120 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery material | 1.2mm thick matte beige faux leather | |
|---|---|---|
| Inner load-bearing frame | Kiln-dried solid eucalyptus wood and 18mm plywood | |
| Seat cushion core | 32kg/m3 high-resilience polyurethane foam with 20mm down wrap | |
| Back cushion core | 24kg/m3 soft polyurethane foam with fiber fill wrap | |
| Seat support system | 3.6mm gauge sinuous steel springs with 50mm elastic webbing | |
| Plinth base | 2mm thick matte black powder-coated carbon steel | |
| Integrated side table top | Upholstered MDF core wrapped in matching beige faux leather | |
| Stitching details | 8 stitches per inch matching beige thread | |
| Frame moisture content | 10% | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed four-position straight seating with segmented seat and back cushions | |
|---|---|---|
| Integrated side table function | Fixed cantilevered right-arm side table for placing drinks, books, or small decor | |
| Back cushion design | Loose, non-reclining back cushions that can be repositioned for comfort | |
| Seat cushion design | Fixed attached seat cushions with stitched segment divisions | |
| Base support function | Recessed dark plinth base creates near-floating visual effect with full floor contact | |
| Seat-to-back angle | 105 degrees | |
| Cover maintenance design | Non-removable upholstery covers for spot cleaning only | |
| Assembly requirement | Minimal on-site attachment of integrated side table; frame delivered as single pre-assembled unit | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room primary seating | Four-person capacity fits open-plan living spaces for family or guest use | |
|---|---|---|
| Modern minimalist interior schemes | Low-profile beige design matches contemporary, wabi-sabi or light luxury decor | |
| Open-concept lounge or reception areas | Neutral color and sleek profile suit small office waiting areas or residential lounge zones | |
| Pairing with low-profile coffee tables | 400mm seat height coordinates with 450 mm high marble or stone coffee tables | |
| Space planning note | Requires 3200mm clear wall length to fit sofa with right-side table extension |
EU Market Access Requirements* EN Standards
| EN 1021-1:2014 | Furniture upholstery fire resistance for cigarette ignition source | |
|---|---|---|
| EN 12520:2015 | Residential furniture seating strength, durability and safety requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood inner frame quality | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood-based panels | |
| GB/T 1952.1-2012 | Safety and performance requirements for upholstered sofas for residential use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood inner frame quality; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood-based panels; 3. GB/T 1952.1-2012: Safety and performance requirements for upholstered sofas for residential use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
