Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2890 x 1680 x 840 mm | |
|---|---|---|
| seat height | 490 mm | |
| main sofa seat depth | 600 mm | |
| chaise lounge depth | 1600 mm | |
| seat cushion thickness | 200 mm | |
| floor clearance under sofa | 150 mm | |
| armrest height from floor | 650 mm | |
| back cushion height | 480 mm | |
| armrest width at front edge | 120 mm | |
| individual seat cushion width | 680 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| gross product weight | 120 kg | |
|---|---|---|
| per-seat static load capacity | 200 kg | |
| seat foam density | 40 kg/m³ | |
| fabric abrasion resistance | 30000 double rubs | |
| cushion rebound rate | 60 % | |
| seam stitch pitch | 30 mm | |
| seat core foam density | 40 kg/m³ | |
| woven fabric abrasion resistance | 30000 double rubs | |
| seat cushion rebound rate | 60 % | |
| upholstery seam stitch pitch | 8 stitches per 30 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| outer arm and frame upholstery | 1.2mm thick saddle tan PU faux leather | |
|---|---|---|
| seat and back cushion upholstery | 320gsm light grey woven polyester linen-look fabric | |
| internal load-bearing frame | Kiln-dried pine solid wood + 12mm thick engineered wood panels | |
| seat cushion fill | 40kg/m³ high-density polyurethane foam core wrapped with 20mm polyester fiber wadding | |
| back cushion fill | 30kg/m³ polyurethane foam mixed with blown polyester fiber | |
| seat support system | 3.8mm diameter zigzag sinuous springs spaced 100mm apart, supported by 50mm wide elastic webbing | |
| support legs | 25mm diameter matte black powder-coated carbon steel cylindrical pin legs, with non-marking PP floor glides | |
| sectional connecting hardware | Zinc-plated steel locking brackets joining main sofa and chaise module | |
| throw pillows included | 5 pieces total, mixed solid woven and geometric plaid fabric covers with polyester fiber fill | |
| seat cushion core construction | 40kg/m³ high-density polyurethane foam core, wrapped with 20mm thick soft polyester fiber wadding | |
| back cushion core construction | 30kg/m³ soft polyurethane foam mixed with 30% blown hollow polyester fiber fill | |
| support leg construction | 25mm diameter matte black powder-coated carbon steel cylindrical pin legs, fitted with 10mm thick non-marking PP floor glides |
Adjustment / rotation / tilt / mobility / storage features
| sectional configuration | Fixed right-facing chaise L-shape, non-reversible layout | |
|---|---|---|
| cushion installation | Loose, reversible seat cushions with non-removable fixed back cushions | |
| floor clearance function | 150mm clearance under frame allows full access for robot vacuums and routine floor cleaning | |
| armrest function | Low-profile angled flared armrests provide padded lateral support without blocking sightlines in open-plan rooms | |
| assembly requirement | Knock-down assembly requiring 2 adults, only leg fitting and sectional bracket connection needed, no frame upholstery assembly | |
| base stability | 8 evenly spaced steel pin legs distributed across main sofa and chaise frame, preventing sagging and frame flex | |
| fixed sectional configuration | Fixed right-facing angled chaise L-shape, non-reversible layout with no modular repositioning slots | |
| cushion design | Loose reversible seat cushions with fixed (non-removable) upholstered back cushions, zippered cushion covers available as a paid upgrade | |
| floor clearance utility | 150mm under-frame clearance accommodates all standard robot vacuum cleaners with up to 140mm body height, allowing full floor cleaning without moving the sofa | |
| armrest ergonomics | Angled flared low-profile armrests with 60mm thick padding, provide lateral arm support at 160mm above seat surface without blocking sightlines in open-plan spaces | |
| structural stability | 8 evenly distributed steel pin legs positioned along front and rear frame rails and chaise corners, eliminate frame flex and sag at module joints under full load | |
| back support function | Four fixed upright back cushions with soft fiber fill, maintain 100 degree lumbar support angle for relaxed seated posture |
Verified carton / gross weight / assembly / loading data
| number of shipping cartons | 3 | |
|---|---|---|
| carton dimensions | 1600 x 850 x 650 mm (main sofa section), 1600 x 900 x 650 mm (chaise section), 500 x 400 x 300 mm (leg/hardware/pillow box) | |
| total gross shipping weight | 130 kg | |
| total shipping volume | 1.3 cbm | |
| assembly time | 50 minutes | |
| 40HQ container loading quantity | 38 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item |
Recommended spaces / users / usage modes
| residential living room | Suitable for compact to medium open-plan living rooms, low-profile silhouette fits modern minimalist and light luxury interior schemes, 4person seating capacity for family and guest use | |
|---|---|---|
| office reception and lounge | Appropriate for informal office breakout areas, executive lounge spaces, and boutique hotel lobbies, neutral two-tone palette coordinates with commercial contemporary interiors | |
| robot vacuum compatible spaces | 150mm ground clearance enables seamless operation of most mainstream robot vacuum cleaners, eliminating the need to move the sofa for routine cleaning | |
| paired furniture recommendation | Pairs with low-profile 1400 mm rectangular or square coffee tables placed 400mm from sofa front edge, and 500mm wide side tables at sofa ends for table lamps and accessories | |
| chaise orientation note | Right-facing chaise layout is optimized for rooms with free floor space on the sofa right side when facing the unit, providing dedicated lounging space without obstructing walkways | |
| residential open-plan living room | Suitable for 120sqm compact to medium apartments, low-profile silhouette aligns with modern minimalist, light luxury, and industrial interior schemes, 4-person seating capacity for family daily use and guest entertaining | |
| light commercial lounge space | Appropriate for informal office breakout areas, co-working lounge zones, boutique hotel lobbies, and design studio waiting areas; 30000 double rub fabric rating supports light daily commercial traffic | |
| low-maintenance smart home spaces | 150mm under-frame clearance is compatible with 98% of mainstream consumer robot vacuum models, eliminating the need to move the sofa for routine floor cleaning in smart home setups |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture - Strength, durability and safety - Requirements for domestic seating, applicable to static load and fatigue performance testing for residential use | |
|---|---|---|
| EN 1021-1:2014 | Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette, applicable to fabric and fill fire safety acceptance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal wood frame structural stability and finish quality acceptance | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission limits for engineered wood frame components | |
| GB/T 1952.1-2012 | General technical requirements for upholstered furniture sofas, applicable to seat load, cushion durability, and structural strength testing | |
| GB/T 17592-2011 | Textiles - Determination of banned azo colourants, applies to compliance testing for all upholstery fabric and faux leather materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal wood frame structural stability and finish quality acceptance; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission limits for engineered wood frame components; 3. GB/T 1952.1-2012: General technical requirements for upholstered furniture sofas, applicable to seat load, cushion durability, and structural strength testing; 4. GB/T 17592-2011: Textiles - Determination of banned azo colourants, applies to compliance testing for all upholstery fabric and faux leather materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
