Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 4200 × 1730 × 800 mm | |
|---|---|---|
| Seat height from floor | 465 mm | |
| Standard seat depth | 650 mm | |
| Chaise lounge depth | 1280 mm | |
| Leg height | 180 mm | |
| Armrest height from floor | 640 mm | |
| Cylindrical armrest diameter | 150 mm | |
| Seat cushion thickness | 230 mm | |
| Back cushion height | 560 mm | |
| Clearance under sofa frame | 150 mm | |
| Total main seating width (excluding chaise) | 2800 mm | |
| Chaise width | 1400 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static weight capacity | 408 kg | |
|---|---|---|
| Per-seat static weight capacity | 102 kg | |
| Seating capacity | 4 people | |
| Net product weight | 250 kg | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Leather surface abrasion resistance | 30000 cycles | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Frame structural warranty | 20 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Contact surface upholstery | Top-grain taupe leather, 1.4 mm thickness | |
|---|---|---|
| Non-contact outer upholstery | Split leather match material | |
| Internal frame | Kiln-dried solid hardwood + engineered plywood, 30 mm section thickness | |
| Seat support system | 3.8 mm diameter high-gauge sinuous steel springs, 50 mm spacing | |
| Back support system | Polypropylene webbing, 70 mm width, 60 mm spacing | |
| Seat cushion fill | 45D high-density polyurethane foam core, wrapped in 50 mm down-fiber blend | |
| Back cushion fill | Blown polyester fiber + down blend, loose reversible design | |
| Armrests | Cylindrical rolled foam core wrapped in matching leather | |
| Support legs | Matte black powder-coated tapered steel, 20 mm tube diameter | |
| Modular connection hardware | Zinc-plated steel interlocking brackets | |
| Accent throw pillow | Matching leather cover, poly-fiber fill | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular assembly | Two primary sections interlock with steel brackets for stable L-shape configuration | |
|---|---|---|
| Leg installation | Threaded metal legs attach to pre-installed frame inserts without permanent fasteners | |
| Cushion placement | Loose seat and back cushions can be rotated or repositioned for even wear | |
| Chaise lounge function | Extended right-side section supports full-leg reclined seating for one user | |
| Under-sofa clearance | 150 mm open space under frame allows robot vacuum access | |
| Orientation option | Chaise can be specified for left or right side during ordering | |
| Armrest function | Padded cylindrical armrests support forearm resting at both open ends of the sectional | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary application space | Large open-plan residential living rooms, minimum 30 sqm area to fit full L-shape footprint | |
|---|---|---|
| Target user group | Households of 5people seeking minimalist luxury lounge seating for daily use and guest hosting | |
| Recommended placement | Positioned against two adjacent walls or as a floating room divider in open concept spaces | |
| Complementary furniture pairing | Pairs with low-profile marble/metal coffee tables of 1400 mm length for coordinated modern aesthetic | |
| Use scenario suitability | Suitable for casual lounging, TV viewing, and extended seated conversation with family and guests | |
| Color coordination | Neutral taupe finish complements light wood, neutral wall, and dark metal interior palettes |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable standard for domestic seating furniture, specifying strength, durability and stability test methods | |
|---|---|---|
| EN 13759:2004 | Applicable standard for furniture hardware, covering performance requirements for interlocking sectional connectors |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB 20400-2006 | Applicable standard for leather upholstery, defining limits for harmful chemical content in leather materials | |
|---|---|---|
| GB/T 3324-2017 | Applicable standard for wooden furniture components, covering dimensional tolerance and finish quality requirements |
This product must meet the following technical requirements: 1. GB 20400-2006: Applicable standard for leather upholstery, defining limits for harmful chemical content in leather materials; 2. GB/T 3324-2017: Applicable standard for wooden furniture components, covering dimensional tolerance and finish quality requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
