Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 900 × 750 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Seat depth (usable) | 600 mm | |
| Individual seat width | 700 mm | |
| Backrest height above seat | 300 mm | |
| Armrest width | 200 mm | |
| Armrest height above seat | 180 mm | |
| Base clearance from floor | 0 mm | |
| Seat cushion thickness | 200 mm | |
| Back cushion thickness | 180 mm | |
| Total seat width (usable) | 2100 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 90 kg | |
|---|---|---|
| Total static load capacity | 340 kg | |
| Seating capacity | 3 adults | |
| Seat foam density | 30 kg/m³ | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 30000 Martindale cycles | |
| Frame static load rating | 450 kg | |
| Warranty period | 3 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Internal frame | Kiln-dried solid pine wood, 30mm section thickness | |
|---|---|---|
| Seat suspension | 8mm sinuous steel springs + 50mm elastic webbing grid | |
| Seat cushion fill | High-density polyurethane foam wrapped with 20mm dacron batting | |
| Back cushion fill | High-density polyurethane foam with button tufting anchoring | |
| Upholstery fabric | 380gsm textured woven dark green polyester blend | |
| Tufting hardware | 15mm plastic upholstery buttons secured with polyester twine | |
| Base structure | Fully upholstered wood plinth base, floor contact with non-slip felt pads | |
| Armrest construction | Integral wood frame padded with 150mm foam, continuous upholstery wrap | |
| Stitching specification | 8 stitches per inch matching fabric thread, hidden seam construction | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Fixed straight three-seat layout with 2 split back cushions and 3 seat sections | |
|---|---|---|
| Tufting function | Full biscuit button tufting across all seat and back surfaces | |
| Base support | Floor-standing plinth base with zero floor clearance, no removable legs | |
| Cushion design | Fixed attached cushions with integrated tufting, no loose removable covers | |
| Armrest function | Integrated padded armrests on both ends, 200mm wide for arm support | |
| Placement adaptability | Free-standing placement suitable for positioning against walls or in open floor plans | |
| Surface stability | Non-slip felt pads affixed to base bottom | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living rooms | Suitable for modern, mid-century and minimalist spaces as primary lounge seating | |
|---|---|---|
| Lobby and lounge areas | Appropriate for boutique hotel lobbies, design studio waiting areas and high-end reception spaces | |
| Small apartment spaces | 2400mm length fits 3-person seating without requiring oversized room dimensions | |
| Designer show flats | Works as statement seating for model homes and interior design showcase installations | |
| Recommended pairing | Coordinates with low-profile coffee tables 400 mm in height to match seating elevation |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture seating strength, durability and stability requirements for residential use | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability test for smouldering cigarette fire safety |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal wood frame structural integrity | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances for wood furniture, applicable to formaldehyde emission control for frame materials | |
| GB/T 1952.1-2012 | Test methods for sofas, applicable to seating load, durability and structural performance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal wood frame structural integrity; 2. GB 18584-2001: Limit of harmful substances for wood furniture, applicable to formaldehyde emission control for frame materials; 3. GB/T 1952.1-2012: Test methods for sofas, applicable to seating load, durability and structural performance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
