Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2200 × 1000 × 880 mm | |
|---|---|---|
| seat height | 420 mm | |
| seat depth per position | 580 mm | |
| seat width per position | 620 mm | |
| armrest height | 620 mm | |
| armrest width | 200 mm | |
| backrest height above seat | 460 mm | |
| base height | 120 mm | |
| cushion thickness | 180 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| total static load capacity | 300 kg | |
|---|---|---|
| net product weight | 75 kg | |
| fabric abrasion resistance | 50000 cycles | |
| foam density | 45 kg/m³ | |
| foam rebound rate | 60% | |
| frame joint static load durability | 10000 cycles | |
| warranty period | 1 year | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| outer upholstery | Full-grain black cowhide leather, 1.4mm thickness | |
|---|---|---|
| inner frame | Kiln-dried solid pine wood, 30mm section thickness | |
| seat cushion fill | High-density polyurethane foam wrapped in 20mm down layer | |
| back cushion fill | 35kg/m³ polyurethane foam with polyester fiber wrap | |
| support system | 80mm wide sinuous steel springs with 50mm elastic webbing | |
| armrest accent panel | Matte grey faux leather or painted composite trim | |
| base upholstery | Matching black leather wrap over rigid wood frame | |
| seam construction | Reinforced polyester thread with 8 stitches per inch | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| seating configuration | Three fixed individual seating positions with segmented cushions | |
|---|---|---|
| recline function | Fixed upright backrest with no powered or manual recline mechanism | |
| arm support | Wide padded armrests on both ends with soft wrapped surfaces | |
| base design | Floor-resting block base with floor protection glides, no exposed legs | |
| cushion design | Tufted segmented seat cushions with fixed attachment to frame | |
| backrest support | Ergonomic curved segmented backrests for lumbar alignment | |
| modularity | Single straight fixed unit, no sectional connector points | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| residential living room | Primary placement for family casual seating paired with coffee table | |
|---|---|---|
| modern apartment open plan space | Low-profile block form fits contemporary minimalist interior design | |
| lounge reception area | Formal but comfortable seating for small office or club guest waiting | |
| recommended configuration | Pair with 1100 mm diameter coffee table and area rug for balanced layout | |
| user capacity | Comfortably seats 3 average adults for daily relaxed seating | |
| maintenance suitability | Smooth leather surface allows easy wipe-clean for regular household use |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| furniture mechanical safety | EN 12520:2015 | |
|---|---|---|
| upholstered furniture flammability | EN 1021:2014 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| upholstered furniture safety | GB 17927.1 | |
|---|---|---|
| furniture dimension marking | GB/T 3327 | |
| furniture formaldehyde emission | GB 18584 |
This product must meet the following technical requirements: 1. upholstered furniture safety: GB 17927.1; 2. furniture dimension marking: GB/T 3327; 3. furniture formaldehyde emission: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
