| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3700 x 1830 x 840 mm | |
|---|---|---|
| Left armed seat unit dimensions | 950 x 950 x 840 mm | |
| Middle armless seat unit dimensions | 950 x 950 x 840 mm | |
| Right open chaise unit dimensions | 1800 x 1500 x 840 mm | |
| Seat height (floor to cushion top) | 470 mm | |
| Seat depth (standard seat units) | 950 mm | |
| Back cushion height (seat to back top) | 380 mm | |
| Armrest height (floor to arm top) | 600 mm | |
| Armrest width | 200 mm | |
| Seat cushion thickness | 250 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Per-seat static weight capacity | 200 kg | |
|---|---|---|
| Total sofa net weight | 150 kg | |
| Seat foam density | 32D | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 30000 double rubs | |
| Cushion sag resistance rating | Grade 4 | |
| Recommended maximum occupancy | 4 people | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal load-bearing frame | Kiln-dried solid pine wood, 30mm thick framing | |
|---|---|---|
| Seat cushion core filling | 32D high-resilience polyurethane foam with 30% down top layer | |
| Back cushion filling | 25D high-resilience foam wrapped in polyester fiber fill | |
| Upholstery fabric | Cream matte linen-blend woven fabric, 380g/sqm weight | |
| Seat support layer | 50mm wide elastic webbing, 80mm spacing under seat cushions | |
| Base construction | Non-slip heavy-duty fabric base, flush to floor with no raised legs | |
| Seam construction | Reinforced stitched seams, 8mm stitch pitch | |
| Included throw pillows | Matching cream fabric covers, filled with polyester fiber | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| Modular unit connection | Independent movable units connected via hidden metal connector clips | |
|---|---|---|
| Cover maintenance | Spot clean with mild detergent, non-removable cushion covers | |
| Base stability | Non-slip textured base prevents shifting on hard flooring or low-pile rugs | |
| Unpacking setup | Vacuum-compressed units expand to full shape within 48 hours, no tool assembly required | |
| Chaise lounge function | Extended open chaise allows full leg rest without arm or back obstruction | |
| Configuration flexibility | Compatible with additional armless/ottoman units to extend seating length | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Ideal for open-plan large apartments and family lounge areas | |
|---|---|---|
| Lobby lounge space | Suitable for high-end residential or boutique hotel waiting areas | |
| Open-concept studio seating | Fits loft and studio apartment layouts without blocking sightlines | |
| Casual lounge configuration | Pairs with low round coffee tables as shown for relaxed entertaining | |
| Residential media room | Provides deep comfortable seating for long-duration media viewing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable standard for domestic furniture seating strength, durability and stability | |
|---|---|---|
| EN 1021-1:2014 | Applicable standard for upholstered furniture ignitability from smoldering cigarette |
Standards applicable to China-market projects
| GB/T 1952.1-2012 | Applicable standard for upholstered sofas, covering durability, safety and dimension tolerance | |
|---|---|---|
| GB 18584-2001 | Applicable standard for formaldehyde emission limits from wooden furniture interior materials |
This product must meet the following technical requirements: 1. GB/T 1952.1-2012: Applicable standard for upholstered sofas, covering durability, safety and dimension tolerance; 2. GB 18584-2001: Applicable standard for formaldehyde emission limits from wooden furniture interior materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
