Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3290 × 2130 × 890 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat depth (main sofa segment) | 580 mm | |
| Chaise lounge segment dimensions | 2030 x 1090 mm | |
| Backrest height from seat | 470 mm | |
| Seat cushion thickness | 250 mm | |
| Support leg height | 80 mm | |
| Main sofa straight segment length | 2200 mm | |
| Leg clearance under sofa base | 50 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Overall product net weight | 98 kg | |
|---|---|---|
| Total static seating weight capacity | 1200 kg | |
| Seating capacity | 4 people | |
| Seat foam density | 38 kg/m³ | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 45000 Martindale cycles | |
| Seam stitch pitch | 30 mm | |
| Factory warranty period | 12 months | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main sofa segment upholstery | Matte light gray woven polyester fabric | |
|---|---|---|
| Chaise segment upholstery | Mustard yellow woven polyester fabric | |
| Seat and back cushion fill | High-density polyurethane foam wrapped in polyester fiber | |
| Internal support frame | Kiln-dried engineered plywood with hardwood bracing | |
| Seat support system | 80mm wide sinuous steel springs with polypropylene webbing | |
| Support feet | Matte black finished solid hardwood block feet | |
| Tufting construction | Stitched biscuit grid tufting securing fabric to cushion cores | |
| Included accent pillows | Polyester fiber fill with removable woven fabric covers | |
| Throw blanket | Woven black and white houndstooth polyester blanket | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating layout | Fixed right-hand facing chaise L-configuration | |
|---|---|---|
| Armless design | Full perimeter without protruding armrests for open modular feel | |
| Cushion configuration | Attached seat and back cushions secured by grid tufting | |
| Assembly requirement | Simple leg attachment assembly with included hardware | |
| Floor protection | Hidden non-slip pads on base of each support foot | |
| Cover maintenance | Spot-clean only upholstery with removable accent pillow covers | |
| Segment connection | Pre-installed steel connection brackets to lock main and chaise segments | |
| Weight distribution | Evenly spaced support feet to prevent sagging on carpet and hard floors | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living rooms | Spacious contemporary living spaces as primary lounge seating for family use | |
|---|---|---|
| Open-plan loft apartments | Low-profile design fits open modern interiors without blocking sight lines | |
| Styling for show homes | Two-tone on-trend colorway suits curated model home and staging projects | |
| Home media rooms | Deep cushioned seats support long-duration relaxed viewing and seating | |
| Small office lounge areas | Casual breakout seating for informal staff and visitor waiting zones | |
| Compact open concept condos | L-shaped layout maximizes corner seating without occupying excess floor space |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture seating strength, durability and safety requirements for structural testing | |
|---|---|---|
| EN 1021-1:2014 | Furniture upholstery flammability resistance to smoldering cigarette ignition |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural frame durability | |
|---|---|---|
| GB 18584-2001 | Limits of harmful substances for wooden furniture, applicable to formaldehyde emission testing | |
| GB/T 19867.1-2005 | Quality requirements for furniture upholstery fabrics, applicable to textile durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural frame durability; 2. GB 18584-2001: Limits of harmful substances for wooden furniture, applicable to formaldehyde emission testing; 3. GB/T 19867.1-2005: Quality requirements for furniture upholstery fabrics, applicable to textile durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
