Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1250 × 790 mm | |
|---|---|---|
| seat height | 450 mm | |
| seat depth | 680 mm | |
| individual seat width | 720 mm | |
| armrest height from floor | 620 mm | |
| armrest width | 220 mm | |
| backrest height from seat | 340 mm | |
| ground clearance under base | 30 mm | |
| seat cushion thickness | 240 mm | |
| backrest cushion thickness | 180 mm | |
| armrest cushion thickness | 150 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| total sofa net weight | 90 kg | |
|---|---|---|
| total static load capacity | 340 kg | |
| seat foam density | 45 kg/m³ | |
| foam rebound rate | 60% | |
| upholstery abrasion resistance | 30000 Martindale cycles | |
| frame joint static load durability | 50000 cycles | |
| seam tensile strength | 180 N | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| internal frame | Kiln-dried solid pine wood, 30mm thick framing | |
|---|---|---|
| seat cushion fill | High-resilience polyurethane foam, wrapped in 20mm dacron layer | |
| backrest cushion fill | 35kg/m³ polyurethane foam with soft polyester fiber wrap | |
| armrest fill | High-density foam core with fiber wrap for curved shape | |
| upholstery fabric | 100% polyester bouclé (lamb fleece) fabric, 380g/m² weight | |
| tufting construction | Stitched grid quilting forming 6 seat/6 back padded segments | |
| seam stitching | Polyester upholstery thread, 8 stitches per 30mm seam pitch | |
| support feet | Black matte PP plastic low-profile feet, 30mm height | |
| internal support webbing | 50mm wide elastic webbing, 80mm spacing under seat | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| seating configuration | 3 equal individual seating positions separated by stitched seams | |
|---|---|---|
| armrest design | Integrated curved padded armrests at both ends with angled slope | |
| back support | Continuous upright padded back divided into 6 grid-tufted segments | |
| positioning feature | Low floor-hugging profile with no recline or adjustment mechanisms | |
| upholstery cover design | Fixed non-removable fabric covers attached directly to frame | |
| floor protection | Smooth plastic feet prevent scuffing on hard flooring surfaces | |
| structural stability | Wide low base with no rocking or motion features for stable seating | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room | Primary use for 3-person family or guest seating in open lounge spaces | |
|---|---|---|
| Small apartment living | Scaled 2400mm width fits compact urban living rooms without overwhelming space | |
| Apartment rental furnishing | Neutral cream color and soft texture works with most interior design styles | |
| Boutique lounge areas | Suitable for boutique hotel lobbies or café casual waiting seating | |
| Recommended pairings | Pairs with low-profile round fabric ottomans and light wood coffee tables | |
| User suitability | Supports 3 average adults comfortably for extended casual seating |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Upholstered furniture safety | EN 1021:2014 | |
|---|---|---|
| Seating strength durability | EN 16139:2013 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture safety | GB 17927 | |
|---|---|---|
| Formaldehyde emission | GB 18584 | |
| Mechanical performance | GB/T 3324 |
This product must meet the following technical requirements: 1. Upholstered furniture safety: GB 17927; 2. Formaldehyde emission: GB 18584; 3. Mechanical performance: GB/T 3324; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
