Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2500 × 1040 × 840 mm | |
|---|---|---|
| seat height | 460 mm | |
| seat depth | 840 mm | |
| seat width | 2240 mm | |
| armrest height | 510 mm | |
| armrest width | 130 mm | |
| backrest height | 380 mm | |
| floor clearance under sofa | 100 mm | |
| minimum required entry door width | 840 mm | |
| seat cushion thickness | 250 mm | |
| back cushion thickness | 200 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| total static load capacity | 449 kg | |
|---|---|---|
| product net weight | 90 kg | |
| seat foam density | 45 kg/m³ | |
| foam rebound rate | 60% | |
| upholstery abrasion resistance | 25000 double rubs | |
| seam stitch pitch | 8 stitches per inch | |
| structural frame warranty | 10 years | |
| fabric and cushion warranty | 1 year | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| outer upholstery | 100% polyester cream boucle (teddy) fabric | |
|---|---|---|
| internal frame | Kiln-dried hardwood and engineered wood composite | |
| seat support system | 3.8mm gauge sinuous S-springs with polypropylene webbing | |
| seat cushion fill | 45kg/m³ high-resilience polyurethane foam | |
| back cushion fill | 38kg/m³ polyurethane foam with polyester fiber wrap | |
| support feet | Black matte polypropylene recessed feet | |
| tufting hardware | Internal fabric-covered buttons and polyester twine tufting ties | |
| upholstery underlayer | 200g/sqm non-woven polyester fabric barrier | |
| armrest internal structure | Padded wood frame wrapped in matching boucle upholstery | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| seating configuration | Fixed 3-seat linear layout with integrated end armrests | |
|---|---|---|
| backrest support | Fixed upright angled backrest at 105 degrees | |
| floor protection | Recessed non-marking plastic feet with integrated felt pads | |
| cushion design | Fixed non-removable tufted seat and back cushions | |
| modular compatibility | Single standalone unit without sectional connection hardware | |
| upholstery care | Surface cleanable with soft brush vacuum and immediate spill blotting | |
| shape retention feature | Biscuit tufting construction secures fill layers | |
| tufted block grid dimensions | 320 x 320 mm | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| residential living room | Primary lounge seating for small to medium family rooms and open-plan living spaces | |
|---|---|---|
| modern minimalist interiors | Matches neutral cream palette and low-profile boxy silhouette for contemporary design schemes | |
| apartment and small home settings | Low-profile form fits compact spaces without overwhelming room layout | |
| reception lounge areas | Suitable for boutique office or residential lobby casual waiting seating | |
| pairing recommendation | Coordinates with low-profile coffee tables 400 mm tall for balanced seating access | |
| fabric suitability | Soft boucle texture appropriate for low to medium traffic residential use |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture strength, durability and safety for seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignition resistance (smoulder test) |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural frame | |
|---|---|---|
| GB 18401-2017 | Textile product safety, applicable to boucle upholstery fabric | |
| GB/T 1952.1-2012 | Technical requirements for upholstered sofas, applicable to performance testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural frame; 2. GB 18401-2017: Textile product safety, applicable to boucle upholstery fabric; 3. GB/T 1952.1-2012: Technical requirements for upholstered sofas, applicable to performance testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
