Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 510 x 450 x 600 mm | |
|---|---|---|
| Top surface thickness | 18 mm | |
| Drawer internal dimensions | 430 x 370 x 120 mm | |
| Open lower shelf internal dimensions | 430 x 370 x 180 mm | |
| Leg height (floor to shelf bottom) | 150 mm | |
| Leg diameter at thickest point | 45 mm | |
| Splay angle of outward-angled legs | 12 degrees | |
| Recessed drawer pull depth | 10 mm | |
| Floor clearance under lower shelf | 100 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 45 kg | |
|---|---|---|
| Unit net weight | 11 kg | |
| Recommended maximum user weight for temporary top seating | 100 kg | |
| Drawer glide cycle life | 10000 open/close cycles | |
| Surface scratch resistance (lacquer finish) | 2H pencil hardness | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top panel, frame and side panels | Solid hardwood (rubberwood/oak category) with clear natural lacquer | |
|---|---|---|
| Drawer front panel | Solid hardwood matching frame, recessed integrated pull | |
| Drawer sides, back and base | Solid hardwood sides/back, hardboard drawer base | |
| Legs | Solid hardwood tapered splayed legs, matching wood finish | |
| Drawer glide hardware | Cold-rolled steel roller glides with anti-pullout stop | |
| Finish coating | Low-VOC clear nitrocellulose lacquer, matte natural sheen | |
| Open shelf panel | Solid hardwood matching frame, reinforced corner joinery | |
| Corner joinery | Mortise and tenon wood joinery for leg to frame connection | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Single full-width drawer with smooth roller glides, anti-pullout safety stop | |
|---|---|---|
| Open storage access | Front-facing open lower shelf for grab-and-go items and stacked books | |
| Surface leveling | Fixed solid wood legs with optional felt floor pads (purchaser installed) | |
| Storage configuration | 1 enclosed upper drawer + 1 open lower shelf, split functional storage | |
| Assembly requirement | Knockdown assembly requiring leg attachment only | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Primary use case | Bedside placement adjacent to standard height beds for nightly essentials | |
|---|---|---|
| Secondary use case | Living room side end table next to sofas or armchairs | |
| Suitable space types | Small bedrooms, studio apartments, boutique hotel guest rooms, minimalist home offices | |
| Matching interior style | Mid-century modern, Scandinavian, Japanese minimalist, natural wood decor schemes | |
| Recommended pairing | Place one on each side of a double or queen size bed for symmetrical storage | |
| Small space suitability | Elevated leg design reduces visual bulk, making rooms appear more open |
EU Market Access Requirements* EN Standards
| Wood furniture formaldehyde recommendation | EN 13986:2004 E1 class (≤0.124 mg/m³) | |
|---|---|---|
| Furniture structural stability recommendation | EN 14749:2016 residential storage unit stability | |
| Surface abrasion resistance recommendation | EN 15185:2011 Class B abrasion rating |
Standards applicable to China-market projects
| Formaldehyde emission limit recommendation | GB/T 18580E0 grade (≤0.05 mg/m³) | |
|---|---|---|
| Wood furniture surface durability recommendation | GB/T 4893.4Class 2 adhesion | |
| Hardware mechanical performance recommendation | GB/T 3324drawer strength requirement |
This product must meet the following technical requirements: 1. Formaldehyde emission limit recommendation: GB/T 18580E0 grade (≤0.05 mg/m³); 2. Wood furniture surface durability recommendation: GB/T 4893.4Class 2 adhesion; 3. Hardware mechanical performance recommendation: GB/T 3324drawer strength requirement; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
