Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 650 x 350 x 1100 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Unit net weight | 32 kg | |
|---|---|---|
| Total static load capacity | 60 kg | |
| Upper shelf static load per level | 15 kg | |
| Recommended storage capacity | 120 L | |
| Tempered glass impact resistance | 50 J | |
| Drawer slide cycle rating | 30000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet frame and legs | Solid rubberwood with natural clear matte finish, 30 mm leg diameter | |
|---|---|---|
| Door and drawer front panels | 18 mm thick MDF with matte off-white lacquer finish, rounded edge trim | |
| Door inserts | 5 mm thick clear tempered glass with polished edges | |
| Handles | Solid rubberwood with natural finish, vertically mounted on doors, horizontal on drawer | |
| Internal cabinet body | 15 mm thick particleboard with warm walnut wood grain laminate interior | |
| Internal shelf | 15 mm thick laminated particleboard, adjustable height with metal support pins | |
| Drawer slides | Cold-rolled steel side-mounted 3/4 extension slides with zinc plating | |
| Door hinges | Cold-rolled steel concealed soft-close hinges with nickel plating | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Upper compartment access | Two side-hinged doors with soft-close mechanism, open 110 degrees for full interior access | |
|---|---|---|
| Internal shelf adjustment | One adjustable shelf in upper compartment with 50 mm increment height positions | |
| Lower drawer operation | Single full-width drawer with 3/4 extension slide, provides concealed storage for small items | |
| Display function | Transparent glass door panels allow dust-protected display of stored items | |
| Elevated base design | Tapered wood legs lift cabinet 200 mm above floor, enabling easy floor cleaning underneath | |
| Door alignment feature | Concealed hinges include 2 mm adjustment range for door gap and alignment | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room application | Place next to sofa as sideboard for tea sets, books and display decor | |
|---|---|---|
| Dining room application | Use as small crockery cabinet to store tableware and dining linens | |
| Bedroom application | Position as small storage cabinet for linens, accessories and personal items | |
| Entryway application | Place in entry hallway for key storage, small items and decorative displays | |
| Small apartment use | Ideal for compact dwellings with 0.23 square meter floor footprint and vertical storage design |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and kitchen storage furniture | |
|---|---|---|
| EN 12150-1:2015 | Thermally toughened soda lime silicate safety glass for furniture use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel and structural performance testing | |
|---|---|---|
| GB 15763.2-2005 | Safety requirements for tempered glass used in furniture door panels, applicable for impact resistance | |
| GB/T 17657-2013 | Test methods for surface finish and physical properties of wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel and structural performance testing; 2. GB 15763.2-2005: Safety requirements for tempered glass used in furniture door panels, applicable for impact resistance; 3. GB/T 17657-2013: Test methods for surface finish and physical properties of wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
