Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 600 x 430 x 1040 mm | |
|---|---|---|
| Leg height (floor to case bottom) | 200 mm | |
| Per-drawer front height | 190 mm | |
| Drawer internal usable width | 520 mm | |
| Drawer internal usable depth | 380 mm | |
| Drawer internal usable height per compartment | 160 mm | |
| Side panel grooved slat width | 20 mm | |
| Clearance between bottom drawer and floor | 200 mm | |
| Frame rail thickness (top/bottom/side) | 40 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total unit net weight | 50 kg | |
|---|---|---|
| Per-drawer static load capacity | 15 kg | |
| Total storage capacity | 170 L | |
| Recommended static top surface load | 20 kg | |
| Drawer slide cycle durability | 50000 open/close cycles | |
| Anti-tip kit required static load resistance | 50 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Case body core material | 18mm thick engineered particleboard/MDF | |
|---|---|---|
| Frame and side panel finish | Light oak wood grain veneer with textured vertical grooved surface | |
| Drawer front finish | Matte off-white polyurethane lacquer, 0.1mm coating thickness | |
| Support legs | Solid rubberwood, tapered splayed profile, clear matte sealant | |
| Drawer slide hardware | Cold-rolled steel side-mount 3-section slides, zinc-plated finish | |
| Drawer box material | 12mm thick MDF for sides, 3mm thick hardboard for drawer bottoms | |
| Back panel material | 3mm thick MDF with oak grain finish | |
| Integrated drawer pulls | Horizontal recess routed into top edge of each lower drawer front | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Pull-out horizontal extension on side-mount slides, 3/4 extension travel | |
|---|---|---|
| Pull type | Integrated recessed horizontal pulls, no protruding external handles | |
| Safety feature | Wall anchoring anti-tip kit included to prevent forward tipping | |
| Drawer stop | Integrated pull-out stop prevents drawers from fully detaching accidentally | |
| Assembly requirement | Flat-pack assembly with included cam lock and screw hardware | |
| Under-unit clearance access | 200mm floor clearance allows robot vacuum and mop access | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Largest individual carton dimensions | 1050 x 500 x 150 mm | |
|---|---|---|
| Total packaged gross weight | 55 kg | |
| Total shipping volume (CBM) | 0.16 m³ | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Bedroom storage | Positioned against wall as narrow dresser for folded clothing and accessories | |
|---|---|---|
| Entryway storage | Placed in entry hall for gloves, scarves and household supplies storage | |
| Living room accent storage | Used as side storage for media accessories, blankets and miscellaneous items | |
| Target user | Urban residents with compact living spaces seeking minimalist wooden storage | |
| Cleaning requirement | Surface clean with dry or slightly damp soft cloth, avoid abrasive cleaners | |
| Placement requirement | Position on level floor, anchor to wall with included anti-tip kit before loading |
EU Market Access Requirements* EN Standards
| EN 14749:2016 Domestic kitchen and storage furniture - Safety and performance requirements | Applicable for structural stability and drawer performance acceptance | |
|---|---|---|
| EN 71-3:2019+A1:2021 Safety of toys - Migration of certain elements | Applicable for surface coating lead/heavy metal limit acceptance for household use |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable as acceptance reference for dimensional tolerance and surface quality | |
|---|---|---|
| GB 18584-2001 Indoor decorating materials - limit of harmful substances in wooden furniture | Applicable for formaldehyde emission and heavy metal content acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable as acceptance reference for dimensional tolerance and surface quality; 2. GB 18584-2001 Indoor decorating materials - limit of harmful substances in wooden furniture: Applicable for formaldehyde emission and heavy metal content acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
