Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 480 x 400 x 550 mm | |
|---|---|---|
| Drawer internal dimensions | 420 x 340 x 120 mm | |
| Open shelf internal dimensions | 420 x 340 x 180 mm | |
| Floor clearance under shelf | 130 mm | |
| Leg height | 150 mm | |
| Tabletop edge radius | 10 mm | |
| Drawer front panel thickness | 18 mm | |
| Carcass side panel thickness | 18 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 30 kg | |
|---|---|---|
| Product net weight | 12 kg | |
| Recommended number of users | 1 | |
| Surface abrasion resistance cycles | 1000 | |
| Drawer slide cycle rating | 50000 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass frame and panels | 18mm CARB P2 grade engineered wood with light oak wood veneer finish | |
|---|---|---|
| Drawer front panel | 18mm engineered wood with matte white UV-cured paint finish | |
| Support legs | Solid rubberwood tapered splayed legs with clear matte lacquer finish | |
| Drawer slides | Cold-rolled steel side-mount full-extension glides with zinc plating | |
| Open shelf surface | Matte light oak veneer matching carcass finish | |
| Tabletop surface | Sealed light oak veneer with rounded edges and water-resistant clear topcoat | |
| Drawer recessed pull | Integrated cutout handle routed into top edge of drawer front | |
| Hardware fasteners | Zinc-plated steel confirmat screws and cam lock fittings | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Upper drawer storage | 1 full-width pull-out drawer with recessed top-edge cutout pull, opens horizontally on metal glides for enclosed personal item storage | |
|---|---|---|
| Lower open storage | 1 full-width open cubby shelf with no door, provides instant-access storage for frequently used bedside items | |
| Elevated leg design | Four outward-angled tapered solid wood legs lift the carcass above floor level, allowing easy floor cleaning under the unit | |
| Rounded edge safety | All exposed tabletop and carcass edges have soft 10mm radius finish to reduce impact injury risk | |
| Surface protection | Sealed veneer and painted surfaces resist common household water splashes and minor scuffs from daily bedside use | |
| Assembly compatibility | Knock-down design with standard cam-lock fittings allows assembly with included basic tools within a short timeframe | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential bedroom bedside placement | Position adjacent to single or double beds to hold lamps, phones, books and nighttime personal items | |
|---|---|---|
| Small living room side end table use | Place next to sofas or armchairs to hold drinks, remotes and small decor items in compact living spaces | |
| Studio apartment multi-use storage | Serve as dual-purpose printer stand, entryway key table or small workspace side storage in tight urban dwellings | |
| Children's bedroom bedside storage | Used next to youth beds with rounded edge design reducing bump injury risk for younger users | |
| Short-term rental furnishing | Install in Airbnb, serviced apartment or dormitory settings for durable, easy-to-clean functional bedside storage |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops safety requirements, applicable for structural stability testing | |
|---|---|---|
| EN 12521:2015 | Domestic furniture strength durability and safety for seating-adjacent storage, applicable for load performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wood-based furniture, applicable for formaldehyde emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wood-based furniture, applicable for formaldehyde emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
