Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 450 × 400 × 550 mm | |
|---|---|---|
| Leg height | 120 mm | |
| Single drawer internal dimensions | 390 x 340 x 120 mm | |
| Top surface thickness | 20 mm | |
| Frame side panel thickness | 18 mm | |
| Drawer front panel thickness | 15 mm | |
| Under-bedside floor clearance | 120 mm | |
| Drawer knob diameter | 30 mm | |
| Leg splay angle from vertical | 12 degrees | |
| Top surface rounded edge radius | 10 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 18 kg | |
|---|---|---|
| Top surface static load capacity | 20 kg | |
| Drawer glide cycle rating | 10000 open/close cycles | |
| Finish scratch resistance rating | 2H pencil hardness | |
| Recommended maximum loaded total weight | 40 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Frame and top panel | Solid pine wood with natural matte clear lacquer finish | |
|---|---|---|
| Drawer front panels | 15mm thick MDF with matte white polyurethane coating | |
| Legs | Solid rubberwood tapered splayed legs with natural finish | |
| Drawer knobs | Solid wood round knobs with brass-toned metal insert accent | |
| Drawer glides | Cold-rolled steel side-mounted 3/4 extension glides | |
| Drawer box construction | 12mm thick plywood drawer boxes with dovetail joinery | |
| Leg foot pads | Non-slip 5mm thick EVA rubber pads | |
| Internal hardware | Zinc-plated steel cam lock and screw fasteners for RTA assembly | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Dual stacked full-width drawers | Provide enclosed concealed storage for bedside essentials, operate on side-mounted metal glides | |
|---|---|---|
| Elevated splayed leg design | Creates 120mm floor clearance for robot vacuum and cleaning access | |
| Round centered drawer knobs | Allow single-handed drawer operation with 20mm grip protrusion from drawer front | |
| Flat square top surface | Supports placement of table lamps, books, drinking cups and small bedside decor | |
| Rounded frame edge detailing | Eliminates sharp corners to reduce impact injury risk in bedroom spaces | |
| Knockdown assembly design | Requires simple leg and handle attachment with included hardware for home assembly | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential master bedrooms | Placed adjacent to single, double or queen size beds for convenient bedside storage | |
|---|---|---|
| Small apartment bedrooms and guest rooms | Compact 450mm width fits narrow spaces without occupying excess floor area | |
| Living room side accent use | Positioned next to sofas or armchairs to hold remotes, drinks and small reading materials | |
| Children’s bedrooms | Rounded corner design reduces collision injury risk with accessible storage height | |
| Mid-century modern and Scandinavian interiors | Two-tone natural wood and white finish matches warm minimalist decor palettes |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Domestic furniture strength, durability and safety requirements for storage units | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage units safety requirements for structural stability | |
| EN 71-3:2019 | Migration of certain elements safety standard for furniture surface coatings |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, formaldehyde emission verification | |
| GB/T 4893.4-2013 | Surface coating adhesion test method for furniture, applicable to finish quality acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, formaldehyde emission verification; 3. GB/T 4893.4-2013: Surface coating adhesion test method for furniture, applicable to finish quality acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
