Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (arranged for use) | 1900 x 1900 x 910 mm | |
|---|---|---|
| Round tabletop diameter | 900 mm | |
| Table overall height | 760 mm | |
| Table umbrella hole diameter | 50 mm | |
| Table lower circular support ring height | 280 mm | |
| Chair overall dimensions (per unit) | 600 x 580 x 910 mm | |
| Chair seat height (top of slats to deck) | 450 mm | |
| Chair seat usable dimensions | 450 x 420 mm | |
| Chair backrest height (seat surface to top of back) | 460 mm | |
| Chair armrest height (top of arm to deck) | 660 mm | |
| Minimum clearance around set required for access | 900 mm | |
| Slat width (table and chair surfaces) | 40 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Table top static load capacity | 100 kg | |
|---|---|---|
| Per-chair static weight capacity | 136 kg | |
| Net weight of complete set | 55 kg | |
| Seating capacity | 4 adults | |
| Frame corrosion resistance rating | 500 hours salt spray | |
| Slat surface UV fade resistance | 1000 hours exposure | |
| Structural racking resistance | 1000 cycle side load test | |
| Surface static friction coefficient | 0.6 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table and chair frame construction | 1.2 mm thick carbon steel with black e-coat primer and polyester powder coat finish | |
|---|---|---|
| Tabletop slats | 20 mm thick weather-resistant WPC composite faux wood, wood-grain textured surface | |
| Chair seat and back slats | 20 mm thick matching WPC composite faux wood, horizontally aligned for drainage | |
| Integrated chair armrests | 20 mm thick WPC slat mounted to steel arm supports | |
| Table leg bracing | 1.5 mm thick steel circular lower ring and vertical center support struts | |
| Umbrella hole fitting | Reinforced steel rim with plastic insert cap included | |
| Foot contact pads | Non-marking polyethylene glides at base of all legs | |
| Hardware kit | Stainless steel 304 bolts and nuts for assembly | |
| Surface finish (metal components) | Matte black textured powder coat, no sharp edges | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Umbrella compatibility | Accepts standard 48 mm diameter patio umbrella poles through central table hole | |
|---|---|---|
| Surface drainage | 10 mm gaps between all horizontal slats direct rainwater off surfaces | |
| Chair design | Fixed stationary frame with no folding, recline or swivel function | |
| Assembly requirement | Knock-down assembly with included hex key and hardware | |
| Maintenance requirement | Wipe clean with damp cloth and mild detergent, no sealing or oiling required | |
| Weight distribution | Four curved table legs transfer load evenly to deck surface | |
| Armrest utility | Wide flat armrests support drinks and small items in addition to arm rest | |
| Stacking capability | Chairs do not stack for storage, fixed rigid frame design | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential patio and deck dining | Ideal for backyard, balcony or garden spaces, weather-resistant for permanent outdoor placement | |
|---|---|---|
| Commercial outdoor cafe seating | Suitable for coffee shop, bistro or restaurant terrace use, durable low-maintenance construction | |
| Small outdoor gathering use | Accommodates 4 adults for meals, drinks or casual conversation around central table | |
| Covered or uncovered outdoor installation | Performs in sun and light rain, no indoor storage required between uses | |
| Matching accessory recommendation | Pair with standard market umbrella and optional weather-resistant seat cushions for added comfort | |
| Surface compatibility | Suitable for installation on wood deck, tile, concrete or stone patio surfaces with level adjustment | |
| Climate suitability | Performs in humid, coastal or high-UV climates with rust-resistant frame and fade-resistant slats | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 Outdoor furniture - Seating and tables for camping, domestic and contract use - General safety requirements | Applicable for structural load and safety verification | |
|---|---|---|
| EN 581-2:2019 Outdoor furniture - Mechanical safety requirements for seating | Applicable for chair static load and durability testing | |
| EN 581-3:2019 Outdoor furniture - Mechanical safety requirements for tables | Applicable for table stability and load capacity verification |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for WPC slat dimensional stability and surface qualityAcceptance inspection | |
|---|---|---|
| GB/T 24821-2009 Outdoor furniture general safety requirements | Applicable for structural stability and sharp edge compliance | |
| GB/T 17657-2013 Test methods for evaluating surface finish durability | Applicable for coating abrasion and corrosion resistance testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for WPC slat dimensional stability and surface qualityAcceptance inspection; 2. GB/T 24821-2009 Outdoor furniture general safety requirements: Applicable for structural stability and sharp edge compliance; 3. GB/T 17657-2013 Test methods for evaluating surface finish durability: Applicable for coating abrasion and corrosion resistance testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
