Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 750 × 750 × 450 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 35 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 91 kg | |
| Surface scratch resistance | 6H pencil hardness | |
| Surface heat resistance | 180 °C | |
| Base static stability load | 150 kg | |
| Floor protection load rating per pad | 25 kg | |
| Surface stain resistance rating | Grade 5 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 12mm thick sintered stone, light neutral matte finish | |
|---|---|---|
| Tabletop edge trim | Matching polished thin edge profile | |
| Pedestal frame | 1.5mm thick cold-rolled steel, truncated conical welded construction | |
| Base exterior finish | Matte black powder coating, anti-fingerprint treatment | |
| Internal connection plate | 3mm thick steel mounting plate, pre-drilled fixing holes | |
| Fixing hardware | M8 zinc-plated steel bolts, 4-point attachment between top and base | |
| Floor contact pads | Non-marking TPE anti-slip pads, fitted to base bottom | |
| Surface sealant | Clear nano-coating on tabletop for stain resistance | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly requirement | Simple knock-down assembly, 4-bolt attachment of top to base | |
|---|---|---|
| Floor protection function | Integrated TPE pads prevent scratches on wood, tile, and stone flooring | |
| Cleaning access | 120mm under-table clearance allows standard robotic vacuum passage | |
| Surface utility function | Non-porous tabletop resists liquid spills and daily wear from beverages and decor | |
| Stability design | Wider bottom pedestal diameter ensures no tip risk with unevenly placed items | |
| Finish maintenance | Matte anti-fingerprint base coating reduces visible smudges from regular contact | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room placement | Center of lounge seating area as primary coffee table for drinks and decor | |
|---|---|---|
| Small apartment lounge spaces | Compact circular footprint with no protruding legs suits tight seating layouts | |
| Modern minimalist interior schemes | Two-tone neutral light top and dark base fits contemporary, wabi-sabi, and light luxury decor | |
| Light commercial lounge areas | Reception waiting areas and office breakout spaces for guest beverage placement | |
| Cleaning-friendly environments | Open under-table space supports automated robotic vacuum cleaning |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Surface safety for furniture | EN 12522:2000 | |
|---|---|---|
| Structural stability for tables | EN 15372:2016 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Occasional table stability | ANSI/BIFMA X2021 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Tabletop material safety | GB 6566 | |
|---|---|---|
| Steel base coating | GB/T 19001 | |
| Furniture structural safety | GB/T 3324 | |
| Hardware durability | GB/T 17645 |
This product must meet the following technical requirements: 1. Tabletop material safety: GB 6566; 2. Steel base coating: GB/T 19001; 3. Furniture structural safety: GB/T 3324; 4. Hardware durability: GB/T 17645; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
