Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 760 x 890 x 970 mm | |
|---|---|---|
| Seat height | 460 mm | |
| Seat width | 580 mm | |
| Seat depth | 550 mm | |
| Backrest height (from seat) | 510 mm | |
| Armrest height (from floor) | 650 mm | |
| Leg base width (front) | 630 mm | |
| Leg base depth (front to rear) | 720 mm | |
| Rear back cutout height | 220 mm | |
| Brass foot cap height | 40 mm | |
| Seat cushion thickness | 80 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static load capacity | 125 kg | |
|---|---|---|
| Net weight (single chair) | 18 kg | |
| Recommended user count | 1 person | |
| Cushion foam density | 45 kg/m³ | |
| Cushion foam rebound rate | 60% | |
| Seam stitching pitch | 30 mm | |
| Surface abrasion resistance (upholstery) | 50000 cycles | |
| Leg static load per unit | 35 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Inner support frame | 1.2mm thick carbon steel tube skeleton | |
|---|---|---|
| Seat upholstery (inner/top surface) | Cream/off-white microfiber leather, 1.0mm thickness | |
| Outer back panel upholstery | Dark brown microfiber leather, 1.0mm thickness | |
| Seat cushion filling | High-density high-elastic polyurethane foam | |
| Backrest filling | 30kg/m³ soft polyurethane foam | |
| Leg structure | 25mm diameter tapered dark powder-coated carbon steel tube | |
| Leg foot caps | Brass-plated zinc alloy decorative caps with anti-skid rubber pads | |
| Frame fasteners | Zinc-plated steel assembly hardware | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating function | Fixed upright seating position optimized for tea table and casual reception use | |
|---|---|---|
| Back support | Curved wraparound integrated back/arm structure provides torso and side support | |
| Arm support | Continuous curved armrests integrated with backrest for relaxed forearm rest | |
| Floor protection | Anti-skid rubber pads under each brass foot cap prevent floor scratching and slippage | |
| Assembly requirement | Simple leg attachment to pre-assembled seat/back frame with included hardware | |
| Mobility | Non-swivel, non-reclining, non-folding fixed structure for stable stationary placement | |
| Cleaning access | Smooth upholstery surface allows spot cleaning with mild detergent | |
| Weight distribution | Four tapered legs spread load evenly to minimize indentation on soft flooring | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Home tea room use | Positioned alongside tea tables for host and guest seating during tea service | |
|---|---|---|
| Living room accent seating | Placed as standalone decorative lounge seating next to side tables or sofas | |
| Commercial reception areas | Used in hotel lobbies, office reception zones or club lounges for guest waiting seating | |
| Balcony/study leisure use | Paired with small side tables in home studies or balconies for casual reading and relaxation | |
| Restaurant/cafe casual dining | Deployed in boutique restaurants or cafes for comfortable dining seating | |
| Hotel guest room seating | Placed in hotel guest rooms next to vanities or window areas for extra seating | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable standard for domestic and contract seating strength, durability and stability requirements | |
|---|---|---|
| EN 1021-1:2014 | Applicable standard for upholstered furniture ignitability resistance to smouldering cigarettes |
Standards applicable to China-market projects
| GB 18584-2001 | Applicable standard for formaldehyde emission limits for interior wooden/metal-upholstered furniture | |
|---|---|---|
| GB/T 19995.1-2005 | Applicable standard for abrasion resistance testing of upholstery leather materials |
This product must meet the following technical requirements: 1. GB 18584-2001: Applicable standard for formaldehyde emission limits for interior wooden/metal-upholstered furniture; 2. GB/T 19995.1-2005: Applicable standard for abrasion resistance testing of upholstery leather materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
