| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 600 x 600 x 985 mm | |
|---|---|---|
| Seat height | 510 mm | |
| Seat width | 590 mm | |
| Seat depth | 520 mm | |
| Armrest height from floor | 700 mm | |
| Seat cushion thickness | 100 mm | |
| Backrest height from seat | 475 mm | |
| Leg outer spread width | 540 mm | |
| Armrest length | 280 mm | |
| Backrest panel thickness | 40 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per chair | 15.9 kg | |
|---|---|---|
| Static weight capacity | 150 kg | |
| Recommended daily user weight | 120 kg | |
| Frame static load rating | 200 kg | |
| Floor protection rating | Suitable for hard floors | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Foam density (seat cushion) | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main frame | 1.5mm thick powder-coated dark bronze steel tube | |
|---|---|---|
| Seat upholstery | 1.0mm thick matte light beige PU leather | |
| Backrest upholstery | Matching light beige PU leather over padded core | |
| Armrest pads | Cylindrical light beige PU padded covers on metal arm supports | |
| Seat padding | 100mm thick high-density polyurethane foam | |
| Back padding | 40mm thick medium-density polyurethane foam | |
| Internal seat support | 8mm thick plywood base under foam | |
| Leg feet | 8mm thick felt floor protection pads | |
| Frame welds | Fully welded joint connections at leg/arm/seat intersections | |
| Seam pitch | 3 stitches per cm | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating posture | Fixed upright 95-degree back angle | |
|---|---|---|
| Base configuration | Fixed non-swivel, non-reclining structure | |
| Armrest support | Fixed 190mm arm clearance above seat | |
| Cleaning feature | Wipe-clean PU upholstery surface | |
| Floor compatibility | Non-marking felt feet suitable for tile, wood, and vinyl floors | |
| Assembly requirement | Knock-down assembly with included hardware | |
| Frame stability | Outward-angled tapered legs with 540mm spread | |
| Stacking capability | Non-stacking design | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential dining rooms | Pairs with standard 750mm height dining tables for everyday family meals | |
|---|---|---|
| Cafes and casual restaurants | Light commercial use for daily customer seating with easy-clean surfaces | |
| Home office and study spaces | Suitable as a desk chair for upright writing or computer work | |
| Hotel guest rooms and lounge areas | Matches modern minimalist interior design schemes for guest seating | |
| Meeting and negotiation areas | Provides firm upright seating for short business discussions | |
| Showroom and display spaces | Works as accent seating for modern furniture or home furnishing displays | |
| Recommended configuration | Pair with 1800 mm long dining tables, 6chairs per table set | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Applicable strength, durability and safety requirements for domestic seating | |
|---|---|---|
| EN 1022:2018 | Applicable test methods for seating stability verification | |
| EN 16139:2013 | Applicable non-domestic seating strength requirements for light contract use |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable to general technical requirements for metal furniture for domestic use | |
|---|---|---|
| GB 18584-2001 | Applicable to limit of harmful substances in wooden and upholstered furniture | |
| GB/T 19001-2016 | Applicable quality management system reference for production consistency |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable to general technical requirements for metal furniture for domestic use; 2. GB 18584-2001: Applicable to limit of harmful substances in wooden and upholstered furniture; 3. GB/T 19001-2016: Applicable quality management system reference for production consistency; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
